- Page 1 StarGazer - Wake Edition Mechanical October 2021 2/14/2023...
-
Page 2: Table Of Contents
Table of Contents Page No. Section 1 Using StarGazer Wake Edition Wakeboard Speed Mode Section 2 Using RPM Mode Section 3 Using Slalom Mode Course Timing (No Mag Timing) Section 4 Using Name List Section 5 Additional Features/Background Settings/System Info. -
Page 3: Using Stargazer Wake Edition
2. [ Read in MPH ^ = Yes ] If you want your system to display in MPH, press the Up Key. For metric, press the Down Key. USING STARGAZER WAKE EDITION There are three operating modes to choose from: (1) Wakeboard/Wake Surf Mode is speed based and controls from the GPS Sensor;... - Page 4 When system is ON, the screen will appear as above with set point speed at left. By using Menu Key you can move around the screen and highlight set point to make speed changes. Once desired speed has been set, you can simply pull up the rider and when set point has been reached or exceeded the system will engage and take over automatically.
-
Page 5: Using Rpm Mode
Section 2 RPM MODE USING RPM MODE In this mode, the screen will appear as follows: 2. Menu Arrow 1. SETPOINT Speed Base Mode Indicator Speed Tachometer Operating in this mode is very similar to using the Wakeboard mode, except the system is now controlling to an RPM SETPOINT. -
Page 6: Using Slalom Mode
5. Timing – If you “MAP” your course, the screen will show your Ball 3 and full course times as you exit the course. Wake Edition - Course Mapping (No Magnet Timing) Step. 1 Locate “Map Courses” on your screen. - Page 7 UP Key at DOWN Key at Entrance in opposite Entrance direction (Entry 2) (Entry 1) Note: Only the entrance gates from each direction will be “mapped”. Step. 3 Starting at one end of the course, idle the boat towards and through the entrance gates.
-
Page 8: Using Name List
Section 4 USING NAME LIST Additional PerfectPass features are accessed by pressing the MENU & UP keys together. The features available vary depending on the make and model of your boat. If a feature is not present on your PerfectPass then it is not available on your system. To move to the next feature press the MENU key. -
Page 9: Additional Features/Background Settings/System Info
Section 5 ADDITIONAL FEATURES / BACKGROUND SETTINGS User Settings – Switch to MPH <>KPH, Set Clock, Turn Compass ON/OFF System Info – Battery Voltage, System Hours, Software / Hardware Version Engine Set Up – To switch from V8 <>V6 Diagnostics – For Servo Motor Testing, (See Trouble shooting for details ) LCD Settings –... -
Page 10: Driving Tips
Section 6 DRIVING TIPS Always pull a rider up smoothly. If you accelerate too far past the target speed, you can gently pull the throttle handle back to assist PerfectPass in taking control. When PerfectPass engages you will hear an audible “beep”. In addition when engaged the Modes (Wakeboard) or Name on Screen will become highlighted. -
Page 11: Troubleshooting/General Information
Section 7 TROUBLESHOOTING / GENERAL INFORMATION Detailed Trouble Shooting documents and videos can be found on line at www.perfectpass.com . See Support, “Trouble shooting”. You can learn a lot from just turning on key and watching system start up. Every time PerfectPass is powered you will see the back light in display turn on followed by a beep as the screen becomes active. - Page 12 alignment with the throttle connection. If you feel the cable is too long, contact PerfectPass) The brass L adapter should freely swivel as the throttle opens & closes. (If your boat has a plastic decorative engine shroud, you may wish to remove it temporarily and see if the problem disappears).
- Page 13 If the Servo Test shows “Failed” then it is likely a bad wire in one of the White Plugs at Servo. (Disconnect & pull gently on each wire to check integrity) If all looks OK then it may be a bad motor. The Gold Resistor on Servo Bracket should be VERY HOT to touch.
-
Page 14: Compass Settings
Use up or down key to adjust time for your area. Press Menu Key when done. Time zone will now be stored in memory. Compass - Normally in the upper left hand corner the screen will show “GPS” when the GPS signal is locked. If you prefer, you can have this screen location show the “Compass Direction”... -
Page 15: Installation
Section 8 INSTALLATION INSTRUCTIONS See Installation Video “Brass L-Adapter” at www.perfectpass.com Step 1. Installation of Servo Motor Using the two provided hose clamps, loosely mount the servo motor on top of the cooling water hose leading to drivers side exhaust manifold (starboard side on standard inboard engines). See Figure A. - Page 16 Step 2. Installation of Master Module Mount the Master Module under the dash normally on the bulkhead accessible behind and right of the passenger seat in a dry location. It can also be installed on th e left side of driver’s bulkhead.
- Page 17 Alternatively, you can locate the solid gray wire in the main wiring harn ess that leads into the Borg Warner control box under the dash. Use a blue “Tee Tap” connector to connect to this gray wire. You can then attach the gray rpm sensor wire to this using a push on spade connector.
-
Page 18: Gps Receiver
Step 9 GPS RECEIVER INSTALLATION Installation: The GPS Receiver can be installed on the dash board looking up through the wind screen. As long as the receiver has a clear unobstructed view of the sky, it will work properly, even if sitting at an angle to the sky. (It can also be installed under the dash looking up through the fiberglass. - Page 19 LIMITED WARRANTY During the first 12 months from date of original retail purchase, any PerfectPass component that fails due to defects in materials or workmanship will be repaired or replaced at the option of PerfectPass at no charge. All warranty claims must be authorized in advance and a Return Authorization (R/A #) issued.
