  • Page 1 PCI8100 User’s Manual Beijing ART Technology Development Co., Ltd.

  • Page 2: Table Of Contents

    PCI8100 Data Acquisition Contents Contents....................................2 Chapter 1 Overview ................................3 Chapter 2 Components Layout Diagram and a Brief Description..................5 2.1 Hardware Structure............................... 5 2.2 The Main Component Layout Diagram........................ 6 2.3 The Function Description for the Main Component..................... 6 2.3.1 Signal Input and Output Connectors ......................

  • Page 3: Chapter 1 Overview

    ART PCI8100 is an Arbitrary-waveform generator board based on PCI bus. It can be directly inserted into IBM-PC/AT or a computer which is compatible with PCI8100. It can be used as signal generating source in a variety of fields such as the laboratory, product quality testing center and so on.
  • Page 4 PCI8100 Data Acquisition Storage Temperature Range: -20℃~70℃ Square-wave Output Channel No.: 1-channel Electric Standard: TTL compatible Maximum pull-down current: 20mA Maximum pull-up current: 2.6mA Input Voltage Range: high voltage≧2.4V, low voltage≦0.7V Other features Board Clock Oscillation: 80MHz Dimension 188mm (L) * 131mm (W) * 22mm (H)

  • Page 5: Chapter 2 Components Layout Diagram And A Brief Description

    PCI8100 Data Acquisition Chapter 2 Components Layout Diagram and a Brief Description 2.1 Hardware Structure SRAM0 Filter circuit EP1C6 Channel-0 （Q240） Internal clock SRAM1 Channel-1 circuit External clock Square output PCI9054 Square wave Trigge External trigger PCI Bus BUY ONLINE at art-control.com/englishs or CALL+86-10-64862359/64861583(CN)

  • Page 6: The Main Component Layout Diagram

    PCI8100 Data Acquisition 2.2 The Main Component Layout Diagram PCI8100 SRAM0 EP1C6Q240C INCLK SRAM1 2.3 The Function Description for the Main Component 2.3.1 Signal Input and Output Connectors AO0: analog output port 0. AO1: analog output port 1. ATR: external analog trigger signal input port.

  • Page 7: Potentiometer

    PCI8100 Data Acquisition 2.3.2 Potentiometer VR1: DA0 analog signal output full-scale point adjustment potentiometer VR2: DA1 analog signal output full-scale point adjustment potentiometer 2.3.3 Reset button RST: the red hardware reset button (EP1C6), press EP1C6, and then the low-level makes the circuit board reset.

  • Page 8: Chapter 3 Connection Ways For Each Signal

    PCI8100 Data Acquisition Chapter 3 Connection Ways for Each Signal 3.1 DA Analog Output Signal Connection 3.2 External Clock Signal Connection 3.3 Square-wave Signal Connection 3.4 External Trigger Signal Connection (DTR) BUY ONLINE at art-control.com/englishs or CALL+86-10-64862359/64861583(CN)

  • Page 9: External Trigger Signal Connection (Atr)

    PCI8100 Data Acquisition 3.5 External Trigger Signal Connection (ATR) If use ART BNC down-lead to connect with output or input signals, please keep in mind that the red port is output/ input signals, the black port is ground. BUY ONLINE at art-control.com/englishs or CALL+86-10-64862359/64861583(CN)

  • Page 10: Chapter 4 The Instruction Of Trigger And Clock Functions

    PCI8100 Data Acquisition Chapter 4 The Instruction of Trigger and Clock Functions 4.1 DA Trigger Function 4.1.1 DA Internal Trigger Mode When DA is in the initialization, if the DA hardware parameter DAPara. TriggerMode = PCI8100_TRIGMODE_SOFT, we can achieve the internal trigger acquisition. In this function, when calling the StartDeviceDA function, it will generate DA start pulse, DA immediately access to the conversion process and not wait for the conditions of any other external hardware.
  • Page 11 PCI8100 Data Acquisition DTR Trigger When the trigger signal is the digital signal (standard TTL-level), using the DTR trigger source. There are two trigger types: edge trigger and pulse level trigger. (1) Edge trigger function Edge trigger is to capture the characteristics of the changes between the trigger source signal and the trigger level signal to trigger DA conversion.

  • Page 12: Internal Clock Function Of Da

    PCI8100 Data Acquisition When DAPara.TriggerDir = PCI8100_TRIGDIR_POSITIVE, it means the trigger level is high. When DTR trigger signal is in high level, DA is in the conversion process, once the trigger signal is in the low level, DA conversion will automatically stop, when the trigger signal is in the high level again, DA will re-access to the conversion process, that is, only converting the data when the trigger signal is in the high level.

  • Page 13: Chapter 5 Notes, Calibration And Warranty Policy

    ART, we will provide good after-sale service and solve the problem as quickly as we can. When using PCI8100, in order to prevent the IC (chip) from electrostatic harm, please do not touch IC (chip) in the front panel of PCI8100 module.
  • Page 14 PCI8100 Data Acquisition 5. To ensure the speed and quality of product repair, please download an RMA application form from our company website. BUY ONLINE at art-control.com/englishs or CALL+86-10-64862359/64861583(CN)

  • Page 15: Products Rapid Installation And Self-Check

    PCI8100 Data Acquisition Products Rapid Installation and Self-check Rapid Installation Product-driven procedure is the operating system adaptive installation mode. After inserting the disc, you can select the appropriate board type on the pop-up interface, click the button【driver installation】; or select CD-ROM drive in Resource Explorer, locate the product catalog and enter into the APP folder, and implement Setup.exe file.
