PCI8932
User's Manual
Beijing ART Technology Development Co., Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCI8932 and is the answer not in the manual?

Questions and answers

Related Manuals for ART Technology PCI8932

Summary of Contents for ART Technology PCI8932

  • Page 1 PCI8932 User’s Manual Beijing ART Technology Development Co., Ltd.

  • Page 2: Table Of Contents

    PCI8932 Data Acquisition V6.018 Contents Contents ....................................2 Chapter 1 Overview ................................3 Chapter 2 Components Layout Diagram and a Brief Description ..................5 2.1 The Main Component Layout Diagram ........................5 2.2 The Function Description for the Main Component ....................5 2.2.1 Signal Input and Output Connectors ......................5 2.2.2 Potentiometer ...............................5...

  • Page 3: Chapter 1 Overview

    ART PCI8932 is a data acquisition module based on PCI bus. It can be directly inserted into IBM-PC/AT or a computer which is compatible with PCI8932 to constitute the laboratory, product quality testing center and systems for different areas of data acquisition, waveform analysis and processing.
  • Page 4 PCI8932 Data Acquisition V6.018 Amplifier Set-up Time: 785ns(0.001%)(max) Non-linear error: ±3LSB(Maximum) System Measurement Accuracy: 0. 1% Operating Temperature Range: 0℃~55℃ Storage Temperature Range: -20℃~70℃ Analog Output Output Range: ±10V, ±5V, 0~10V, 0~5V 12-bit resolution Set-up Time: 10μs (0.01%) Channel No.: 4-channel Non-linear error: ±1LSB(Maximum)

  • Page 5: Chapter 2 Components Layout Diagram And A Brief Description

    PCI8932 Data Acquisition V6.018 Chapter 2 Components Layout Diagram and a Brief Description 2.1 The Main Component Layout Diagram 2.2 The Function Description for the Main Component 2.2.1 Signal Input and Output Connectors CN1: Analog signal input and output connectors...

  • Page 6: Jumper

    2.2.4 Physical ID of DIP Switch DID1: Set physical ID number. When the PC is installed more than one PCI8932 , you can use the DIP switch to set a physical ID number for each board, which makes it very convenient for users to distinguish and visit each board in the progress of the hardware configuration and software programming.

  • Page 7: Status Indicator

    PCI8932 Data Acquisition V6.018 DID1 The above chart shows"0111", so it means that the physical ID is 7. DID1 The above chart shows"0101", so it means that the physical ID is 5. Physical ID （Hex） Physical ID （Dec） OFF（0） OFF（0）...

  • Page 8: Chapter 3 Signal Connectors

    PCI8932 Data Acquisition V6.018 Chapter 3 Signal Connectors 3.1 The Definition of Signal Input and Output Connectors 37 core plug on the CN1 pin definition Pin definition about CN1: Pin name Pin feature Pin function definition AI0~AI15 Input Analog input, reference ground is AGND.

  • Page 9: Digital Input Connector

    PCI8932 Data Acquisition V6.018 3.2 Digital Input Connector 20 core plug P1 pin definition P1 pins definition Signal Name Type Function definition DI0-DI15 Input Digital signal input pins, reference ground is DGND. DGND Digital signal ground 3.3 Digital Output Connector...

  • Page 10: Chapter 4 Connection Ways For Each Signal

    Single-ended/double-ended mode can be set by the software, please refer to PCI8932 software manual. According to the diagram below, PCI8932 board can be connected as analog voltage double-ended input mode, which can effectively suppress common-mode interference signal to improve the accuracy of acquisition. Positive side of the 8-channel analog input signal is connected to AI0~AI7, the negative side of the analog input signal is connected to AI8~AI15, equipments in industrial sites share the AGND with PCI8932 board.

  • Page 11: Other Connections

    PCI8932 Data Acquisition V6.018 4.3 Other Connections Figure 4.3 analog signal output connection Figure 4.5 digital signal output connection Figure 4.6 Clock Input/Output and Trigger Signal Connection Figure 4.4 digital signal input connection BUY ONLINE at art-control.com/englishs or CALL+86-101-51289836(CN)

  • Page 12: Chapter5 Subtractive Counter

    PCI8932 Data Acquisition V6.018 Chapter5 Subtractive Counter Mode 0: Interrupt on terminal count Under this mode, when given the initial value, if GATE is high level, the counter immediately begins to count by subtracting “1” each time, the counter output OUT turns into low level; when the count ends and the count value becomes 0, the counter output OUT becomes and keeps high level until given the initial value or reset.
  • Page 13 PCI8932 Data Acquisition V6.018 Figure 2 Mode 2: Rate Generator Under this mode, the counter is given the initial count value N and begins to count from (N-1), OUT becomes high level. When the count value becomes 0, OUT turns into low level. After a CLK cycle, OUT resumes high level, and the counter automatically load the initial value N and begin to count from (N-1).
  • Page 14 PCI8932 Data Acquisition V6.018 Mode 4: Software triggered strobe Under this mode, the counter is given the initial count value N and begins to count, the output OUT becomes high level. When the count value becomes 0, it immediately outputs a negative pulse which is equal to the width of one clock cycle.

  • Page 15: Chapter6 Notes, Calibration And Warranty Policy

    Every device has to be calibrated before sending from the factory. It is necessary to calibrate the module again if users want to after using for a period of time or changing the input range. PCI8932 default input range: ±10V, in the manual, we introduce how to calibrate PCI8932 in ±10V, calibrations of other input ranges are similar.

  • Page 16: Use

    PCI8932 Data Acquisition V6.018 6.4 DA use In demonstration program, the continuous output interval of waveform output can not be carried out; the main objective is to test the strength of DA output. 6.5 Warranty Policy Thank you for choosing ART. To understand your rights and enjoy all the after-sales services we offer, please read the following carefully.

  • Page 17: Products Rapid Installation And Self-Check

    PCI8932 Data Acquisition V6.018 Products Rapid Installation and Self-check Rapid Installation Product-driven procedure is the operating system adaptive installation mode. After inserting the disc, you can select the appropriate board type on the pop-up interface, click the button【driver installation】; or select CD-ROM drive in Resource Explorer, locate the product catalog and enter into the APP folder, and implement Setup.exe file.
