ASCB1系列智能微型断路器 ASCB1 series intelligent smart circuit breakers 安装使用说明书 V1.0 installation and operation manual 江苏安科瑞电器制造有限公司 Jiangsu Acrel Electric MFG. Co., Ltd.
Page 2
申 明 版权所有,未经本公司之书面许可,此手册中任何段落、章节内容均不得摘 抄、拷贝或以任何形式复制、传播,否则一切后果由违者自负。 本公司保留一切法律权利。 All rights reserved. Without written permission of the company, any paragraph or chapter in this manual shall not be copied, copied, reproduced or disseminated in any form. Otherwise, all consequences shall be borne by the violators.
5.3.1. 当前设备状态显示 The current device status is displayed ...... 8 1. Summarize ASCB1 series of intelligent miniature circuit breakers are used for low-voltage terminal distribution network in industrial, commercial, civil buildings and infrastructure fields in indoor buildings and similar places. The intelligent circuit...
Page 4
protection, short circuit protection, energy metering statistics, fault location and so This series of products are suitable for single phase, double live wire, three phase three wire, three phase four wire neutral point direct grounding (TT) low voltage power grid system. 2.
Smart Gateway Ethernet Gateway Acrel Function Up to 18 intelligent circuit breakers can be connected; View the real -time data of voltage, current, power, electric energy, temperature ASCB1-M-CE and leakage of each intelligent circuit breaker Up to 18 intelligent circuit breakers can be connected; View the real...
Page 6
20mA warning,30mA trip Manual button self-test 20000 times 6000 times IP20 1-35 mm² 2000m -10℃~45℃ -20℃-70℃ 35mm Din rail installation Smart Gateway technical parameters ASCB1-M-4G ASCB1- M-CE AC 220V ≤30W Ethernet Modbus、 MQTT 2000m -10℃-45℃ -20℃-70℃ IP20 35mm Din rail installation 第...
Page 8
Sm a r t ga t e w a y 图3 Smart Gateway outline dimensional drawing 图 4 Terminal diagram 4.2. Installation method 1) The equipment is suitable for standard 35mm guide rail installation, installation only need to put the equipment into the track and buckle fixed.
Page 9
Internet of Things modules and specifications of the electrical box, and install the modules in combination according to the sequence shown in the picture. Each module is connected with the manufacturer's special 8-pin data cable. 3) The circuit breaker should be installed vertically. When the handle is in the "/OFF"...
Terminal wiring diagram 5. Operation Guide Intelligent circuit breaker 5.1. button panel and indicators Panel button instruction: ON/OFF:Short press:On/off brake,Long press 3S:State of repair; T/ Press once a month or RESET: short press the leakage test button, long press 3S: alarm RESET and reclosing times return to zero; Lock:Local lock on and off;...
