Summary of Contents for Acrel ASCB1 Series

  • Page 1 ASCB1 series intelligent miniature circuit breaker Installation Manual V1.0 Jiangsu Ankerui Electric Appliance Manufacturing Co., Ltd. Jiangsu Acrel Electric MFG. Co., Ltd.
  • Page 2 declare All rights reserved. Without the written permission of the company, any paragraphs and chapters in this manual shall not be excerpted, copied or reproduced or transmitted in any form, otherwise all consequences shall be borne by the offender. The company reserves all legal rights. The company reserves the right to modify the product specifications described in this manual without prior notice.
  • Page 3: Table Of Contents

    target record 1. Overview ..............1 2. Product Model ..............1 3. Technical parameters ............3 4. Installation and wiring ............5 4.1. Outline and installation dimensions (unit: mm) ......5 4.2. Installation method ............ 7 4.3. Wiring example Figure ..........8 5.
  • Page 4: Overview

    1. Overview ASCB1 series intelligent miniature circuit breakers (hereinafter referred to as intelligent miniature circuit breakers) are used in low-voltage terminal power distribution networks in industrial, commercial, civil buildings and infrastructures in indoor buildings and similar places. The intelligent miniature circuit breaker is used in conjunction with the intelligent gateway to conduct real-time monitoring of the key electrical parameters of the power line, such as voltage, current, power, temperature, leakage, energy consumption, etc.
  • Page 5 Table 1 Function description table of intelligent miniature circuit breaker Product number Function description It can monitor parameters such as voltage, current, power, energy and temperature in real time; it has various protection functions such overvoltage, undervoltage, overload, short circuit, overcurrent, and overtemperature;...
  • Page 6: Technical Parameters

     Smart Gateway A SCB 1 - M - □ 通讯方式:CE 以太网通讯 4G 4G通讯 产品类别: 网关 开发代号:1 产品代号:SCB 智能断路器Smart Circuit Breaker缩写 企业代号: A 安科瑞 Table 2 Intelligent gateway function description table Can connect up to 16 intelligent miniature circuit breakers; can view real-time data such as voltage, current, power, electric energy, temperature and leakage of each intelligent miniature circuit breaker;...
  • Page 7 Storage -20℃-70℃ temperature pollution level Ⅲ installation type Installation Standard 35mm rail installation method Table 4 Technical parameter table of ASCB1 series intelligent gateway Product number ASCB1-M-4G ASCB1-M-CE Working power AC 220V Power consumption ≤30W _ _ communication Ethernet method 第...
  • Page 8: Installation And Wiring

    Display method LCD dot matrix liquid crystal display record Alarm, fault and action records up to 20 records each protocol Modbus, MQTT, etc. Altitude 2000m requirements ambient temperature -10℃- 55 ℃, 24h average temperature not higher than 40 ℃ Environmental No explosion hazard, no conductive dust, no enough to corrode metal requirements and destroy insulation, no significant vibration...
  • Page 9 Figure 2 Schematic diagram of intelligent miniature circuit breaker wiring terminal  Smart Gateway Figure 3 Outline Dimension of Smart Gateway 第 6 页...
  • Page 10: Installation Method

    Figure 4 Schematic diagram of smart gateway wiring terminals 4.2. Installation method 1) The device is suitable for standard 35mm rail type installation. When installing, just clip the device into the rail and fix it with a buckle . 2) According to the actual power distribution management and line laying design requirements, select and use IoT modules and electrical boxes that meet the needs The specifications of the box are assembled and installed in the order of the modules shown in the figure, and each module is connected by a special 8PIN data cable made by the...
  • Page 11: Wiring Example Figure

    Figure 5 Installation and wiring example diagram 4.3. Wiring example diagram 最大数量16台 example diagram of intelligent miniature circuit breaker Figure 7 Schematic diagram of 4pin terminal wiring (top view) Note: Various types of intelligent miniature circuit breakers can be installed in any combination, and one gateway can connect up to 16 intelligent miniature circuit breakers .
  • Page 12: Description Of Intelligent Circuit Breaker Button Panel And Indicator Light

    5.1. Description of the key panel and indicator lights of the intelligent miniature circuit breaker Figure 8 Description of the smart miniature circuit breaker button panel Key Description:  ON/OFF: Short press: open and close button, long press for 3S: maintenance state enters and exits;...
  • Page 13: Interface Operation

    Figure 9 Description of smart gateway button panel Key Description:  ESC/ : Confirm or return key;  ▲: page up;  ▼: page down; Indicator light description:  Green light: 2s off, 0.1s flashing, running state;  Red: If it goes out for 2s and flashes for 0.1s, there is a circuit breaker fault;...
  • Page 14: Display And Setting Of Equipment Protection Parameters

    EPI represents the value of absorbed active energy, EPE represents the value of released active energy, EQL represents the value of inductive reactive energy, and EQC represents the value of capacitive reactive energy. 5.3.3. Display and setting of equipment protection parameters On the main interface, press the Enter key, select "Device List", press the Enter key, select the circuit breaker whose protection parameters need to be set, for example: "03: ASCB1-63-3P", press the Enter key twice, select "...
  • Page 15: Query Of Device Event Records

    5.3.5. Query of device event records Return to the home page of the smart gateway, select "Device List", select the circuit breaker whose event record needs to be viewed, for example: "03: ASCB1-63-3P", press the Enter key twice, select "Event Record" and press the Enter key to view Alarm, fault and switch records.
  • Page 16: Notes

     9 Close the server connection  TX: The number of sent data is displayed after TX  Rx: The number of received data is displayed after Rx Under the information interface (2) interface, the first line displays the domain name ( if no domain name is set, it will not be displayed ), The second line shows the port number to connect to the server .
