Thank you for purchasing the Power Inspired GATEWAY. The GATEWAY is a battery backed AC
power supply designed for door access systems. Unlike standard battery backup systems which
revert to battery immediately following a power failure, it is intended that the GATEWAY remains off
until awoken when needed with an external switch contact. This prevents unnecessary battery
discharge and extends power availability from hours to weeks.
The Gateways can be used in standard UPS mode (where no remote contacts are incorporated) or in
sleep mode. When in sleep mode the unit is activated using an external switch or relay. Wireless
relays or other controllers can also be incorporated using a 24Vdc supply provided by the GATEWAY.
The GATEWAY is compatible with leading control equipment incorporating UPS sleep mode on RJ11
connectors.
Please read this manual before using the GATEWAY-SX.
1.
SYMBOLS USED IN THIS MANUAL
✍
A Useful Point To Note
⚠
A Warning which must be heeded or damage or injury could occur.
Danger of High Voltage
2.
CAUTIONS & WARNINGS
⚠
Indoor Use Only
⚠
Do not operate the GATEWAY without the mains input plug being connected to an
earthed socket outlet.
⚠
Do not allow the GATEWAY to come into contact with any liquid.
Do not open the unit. Hazardous Voltages can exist even though the unit is switched
off.
This unit contains lead acid batteries and must not be discarded in normal waste.
Contact your local waste processing centre or return to Power Inspired for disposal.
GATEWAY-SX
On Demand AC Power
With Sleep function
Advertisement
Table of Contents
Related Manuals for Power Inspired GATEWAY-SX
Summary of Contents for Power Inspired GATEWAY-SX
- Page 1 On Demand AC Power With Sleep function Thank you for purchasing the Power Inspired GATEWAY. The GATEWAY is a battery backed AC power supply designed for door access systems. Unlike standard battery backup systems which revert to battery immediately following a power failure, it is intended that the GATEWAY remains off until awoken when needed with an external switch contact.
- Page 2 Note that the inverter is only active when no mains supply is available and the GATEWAY is in battery mode. ✍ The GATEWAY-SX will charge and maintain charge on the battery when connected to AC power, regardless of whether the unit is switched on or not. MAN-GW-SX Rev1.2...
-
Page 3: Led Display
Power Inspired GATEWAY-SX Series Product Manual IDENTIFICATION ❶ ➎ LED Display – see below RJ45 Ports for Sleep function ❷ ➏ ON/OFF Switch Mains input and input fuse ❸ ➐ USB Port Output IEC connections Fan – active only when UPS is in battery or ➍... -
Page 4: Installation
Power Inspired GATEWAY-SX Series Product Manual INSTALLATION • If the unit is to be mounted in a ceiling void or at height, please ensure the unit is adequately supported and cannot fall. • Ensure cables are not loose and cannot snag on moving parts •... - Page 5 Power Inspired GATEWAY-SX Series Product Manual CONNECTING TO AN EXTERNAL SWITCH OR CONTROLLER • On the rear of the GATEWAY are two RJ connectors • To remote start the unit the SW connections must be shorted together. • To switch the unit off the SW connection must be opened.
- Page 6 Power Inspired GATEWAY-SX Series Product Manual OPERATION – Remote / Sleep Mode • Switch on utility power supplying the GATEWAY. It is suggested to ensure the GATEWAY has at least 6 hours of uninterrupted connection to the utility to ensure the batteries are adequately charged.
-
Page 7: Specifications
Power Inspired GATEWAY-SX Series Product Manual SPECIFICATIONS GW1200-SX Model Capacity (Max Watts) 1200W Input Voltage 230VAC 50Hz Nominal Input Voltage Range 162-290VAC Output Voltage Regulation 230VAC ±10% (Battery Mode). As input in normal mode Output Waveform Battery Mode Pseudo-Sine (Square) Wave... -
Page 8: 10. Troubleshooting
Power Inspired GATEWAY-SX Series Product Manual 10. TROUBLESHOOTING PROBLEM POSSIBLE CAUSE SOLUTION LED Display Blank No Mains Power Connect Power. Check Fuse. Poor AC input connection Confirm Connection Unit starts up on battery but Insufficient Charge On Recharge for 6 hours. If... - Page 9 1. The Gateway is warranted from defects in material and workmanship under normal use during the warranty period. 2. During the warranty period Power Inspired will repair or replace at no charge, the product or parts of it that proves defective because of improper material or workmanship under normal use or maintenance.
