- Page 1 Addressable fire alarm sounder for outdoor use SPP-401 Firmware version 1.00 spp-401_en 02/23 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 IMPORTANT The device should be installed by qualified personnel. Prior to installation, please read carefully this manual in order to avoid mistakes that can lead to malfunction or even damage to the equipment. Disconnect power before making any electrical connections. Changes, modifications or repairs not authorized by the manufacturer shall void your rights under the warranty.
-
Page 3: Installation
The SPP-401 outdoor sounder is used for acoustic alarm signaling. It is designed to operate in the detection line of the ACSP-402 addressable fire alarm control panel. 1. Features Acoustic signaling by means of piezoelectric transducer. Signaling controlled by the control panel: –... - Page 4 SPP-401 SATEL...
- Page 5 SATEL SPP-401 8. Connect the detection line wires to the sounder (Fig. 6 – loop; Fig. 7 – radial circuit). To terminals A+ and A-, connect the wires from the control panel / previous device. Connect the wires to terminals B+ and B- to connect the sounder to the next device / control panel.
- Page 6 SPP-401 SATEL...
-
Page 7: Acoustic Signaling
SATEL SPP-401 3. Acoustic signaling Configure the acoustic signaling settings in the control panel. For each alarm condition you can select one of the 32 available tones (see: Table 1). Acoustic signaling Frequency Hz Description 2 Hz (250 ms – 250 ms) 800 &... - Page 8 SPP-401 SATEL 3 x 500 ms sound, 1.5 s silence, repeated 800-970 3 x 500 ms sound, 1.5 s silence, repeated 970 & 800 3 x 500 ms sound, 1.5 s silence, repeated 2400 Continuous 2 Hz (250 ms – 250 ms) (Symphoni Tones) 990 &...
-
Page 9: Maintenance
SATEL SPP-401 Angle-dependent [°] minimum sound level [dBA] Tone / supply voltage 15° 45° 75° 105° 135° 165° 18 / 18 VDC 77.9 86.8 89.1 88.9 85.1 77.3 18 / 26 VDC 88.2 87.7 92.2 92.6 88.8 81.9 19 / 18 VDC 78.0... -
Page 10: Specifications
SPP-401 SATEL 5. Specifications Supply voltage ....................... 18...26 VDC Quiescent current consumption ..................0.25 mA Alarm current consumption ....................4 mA Operating temperature range ................-25°C...+70°C Maximum humidity ......................95% Protection rating ......................... IP65 Operating environment type ....................B Dimensions ....................108 x 108 x 96 mm... - Page 11 The SPP-401 fire alarm sounder has been granted the Certificate of Admittance No 4768/2022 by the CNBOP-PIB in Józefów. The Certificate of Admittance can be downloaded from the www.satel.pl website. SATEL Sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND 1438 1438-CPR-0859...
