M951
END TRIMMER FOR SHAPED AND STRAIGHT PANELS
KAPOVACÍ KLEŠTĚ NA TVAROVÉ I ROVNÉ DÍLCE
KAPOVACIE KLIEŠTE NA TVAROVÉ AJ ROVNÉ DIELCE
ÉL VÉGLEVÁGÓ ÍVES ÉS EGYENES MUNKADARABOKHOZ
SZCZYPCE TNĄCE DO FORMATOWYCH I PŁASKICH ELEMENTÓW
Model and specifications:
Model: M951
Dimension: 240 x 52 x 138 mm
Maximum Cutting Width: 62 mm
Maximum Cutting Thickness: 3 mm
!!! Maximum cutting width, thickness does not apply to all materials !!!
End To End Cutting
Use the fixing board to adjust the cutting length. To have a more precise cut,
align the correction block by the starting point of the edge band.
Place the fixing board against top edge band to set up the correct angle for
cutting.
Insert the extra portion of the tape through the entrance of the blade, align
the correction block, hold that extra portion firmly, press the handle of the
cutter to cut the tape, then use the heat gun to reheat the glue, and press the
tape to the work piece for banding.
End Cutting
For straight edge cuts, flip the correction block against the surface, insert the
spare edge band through the cutting gap, aligned properly and grasp on the
cutter.
The hold knob can be adjust to fit personal operation preferences.
