Identify all parts packed in the carton against the parts list. Remove all protective
materials. Place parts on a non-abrasive surface to avoid scratching.
Do Not Attempt Assembly If Any Parts Are Missing Or Damaged.
Warning: Please do not use acid or alkaline washing liquid to clean the product.
Chair have a 275 lbs weight capacity.
Assemble the product as shown below, step-by-step.
Part List
NO.
SKETCH
DESCRIPTION
A
Seat Frame
B
C
Seat Cushion
D
Back Cushion
E
Assembly Instructions
QTY
1
1
Base
1
1
Foot
Pre-assembled
at factory
NO.
SKETCH
DESCRIPTION
AA
(M8*45)
Steel Washer
BB
(Φ12.5*Φ8.5*2)
Steel Washer
CC
(Φ16*Φ8.2*1.0)
DD
Steel Washer
EE
Bolt Cap
FF
(19*16.5*9)
GG
(19*16.5*17)
HH
JWUA
SKU#74651069
QTY
Bolt
4
4
4
4
4
Nut
4
Bolt Cap
4
2
Wrench
GLA-5106-11
Made in China
1
