GV-3008
The GV-3008 Card provides up to 8 video and 8 audio channels, recording up to 240 / 200
fps (NTSC / PAL) in total with H.264 hardware compression. The GV-3008 Card provides the
high-resolution live image with DSP Overlay. Even in multi views, the image on the largest
division view can remain at the high-quality resolution.
Minimum System Requirements
32-bit
Windows XP / Windows Vista / Windows 7 / Windows Server 2008
OS
64-bit
Windows 7 / Windows Server 2008
GV-3008
CPU
GV-3008 x 2
GV-3008
RAM
GV-3008 x 2
GV-3008
HDD
GV-3008 x 2
AGP or PCI-Express, 800 x 600 (1280 x 1024 recommended), 32-
Graphic Card
bit color
DirectX
9.0c
Power Supply
400 Watts
Packing List
1. GV-3008 Card x 1
2. 1-4 D-Type Video and Audio Cable x 1
3. 5-8 D-Type Video and Audio Cable x 1
November 28, 2011
Core 2 Duo, 2.33 GHz
Core 2 Quad, 2.4 GHz
2 x 1 GB Dual Channels
250 GB
500 GB
4. Hardware Watchdog Jumper Wire x1
5. Software DVD x 1
6. Surveillance System Quick Start Guide x 1
1
Connecting One GV-3008 Card
•
Connect the D-Type video and audio cables to the GV-3008 Card.
•
Connect the supplied Hardware Watchdog Jump Wire (Figure 3).
•
Connect the computer's internal power supply to the GV-3008 Card. The Power LED
should be lit in green to indicate the card is ready for use.
Figure 1
2
November 28, 2011
Advertisement
Table of Contents
Related Manuals for GeoVision GV-3008
Summary of Contents for GeoVision GV-3008
- Page 1 • Connect the D-Type video and audio cables to the GV-3008 Card. The GV-3008 Card provides up to 8 video and 8 audio channels, recording up to 240 / 200 • Connect the supplied Hardware Watchdog Jump Wire (Figure 3).
- Page 2 Connecting Two GV-3008 Cards You can install two GV-3008 Cards for a total of 16 channels. Master Card is the card with 1- 8 channels and Slave Card is that with 9-16 channels. The Master and Slave cards can be...
- Page 3 To restart the computer automatically by the hardware watchdog on the GV-Video Capture After installing the GV-3008 Card in the computer, insert the software DVD to install GV- Card, a connection needs to be made from the card to the motherboard.
- Page 4 DVR, will be transmitted directly to remote servers To take full advantage of GV-3008 Cards, you can adjust the video settings, including the instead of being compressed again on the DVR. The remote servers include CMS-related recording quality and frame rate, before running the GV-System.
- Page 5 2.5M ~ 10M GV-NET/IO Card Support GV-Multi Quad Card Support GV-Loop Through Card Support Dimensions (W x H) 180 x 112 mm / 7.09 x 4.41 in Note: GV-3008 does not support the TV-Out function. November 28, 2011 November 28, 2011...
