2 Specifications
Specifications
Power 10W
Impedance 75 Ohms
Line Voltage 25 V
Sensitivity 92 dB
Enclosure Material Lexan Polycarbonate plastic
Frequency Response 100 Hz to 10 kHz
Connectors Phoenix Screw Connector
Driver 11 cm (4.5") full range
Color White (RAL9016)
Anchor Device 5mm plastic hook at the center
Seismic Security Additional 5mm metal hook
Certification UL 62368 in process
Weight 1.26 kg (2.8 lbs)
Shipping Weight 1.66 kg (3.7 lbs)
Box Dimensions To be confirmed
172mm
99mm
167mm
3
