Genelec 4435A Operating Manual page 8

SYSTEM SPECIFICATIONS
Lower cut-off frequency, -6dB
Upper cut-off frequency, -6dB
Frequency response within ± 2.5 dB
Minimum delay from analogue input to acoustic output
Maximum short-term sine wave output on axis in half space, average 100 Hz
to 3 kHz, at 1 m, using PoE+ power
Maximum long-term RMS acoustic output in same conditions with IEC-weighted
noise, at 1 m using PoE+ power (limited by driver unit protection circuit and
the PoE power supply being used)
Maximum peak acoustic output per unit in a listening room with music material,
at 1 m, using PoE+ power
Self-generated noise level in free space, at 1 m on the acoustical axis, A-weighted
Harmonic distortion at 85 dB SPL at 1 m on axis
frequency range 70 – 200 Hz
frequency range >200 Hz
Dispersion angle (degrees), horizontal
Dispersion angle (degrees), vertical
Bass driver
Treble driver
Weight
Dimensions H x W x D
Maximum short-term output level is limited by the PoE technology being used and the crest factor of the audio signal. The stated values are typical for music and speech signals.
Maximum long-term output level can be further limited by loudspeaker system protection. Genelec recommends using PoE+ whenever possible. Using lower-power PoE can limit short-term
maximum and long-term maximum, depending on the characteristics of the signal being reproduced.
User selectable filters can be set to positive gain. Positive gain must be used with care as it is possible to cause premature overload of the loudspeaker at specific frequencies.
INPUT / CROSSOVER SECTION
Ethernet connection
Nominal SPL with 0 dBFS digital audio input at maximum sensitivity
Audio-over-IP streaming formats
Analogue input, connector type
Analogue input, Input impedance
Analogue input level for 100 dB SPL at 1 m
Analogue input, maximum input signal
Crossover frequency, bass/treble
Number of user-adjustable filters
User selectable filters, choice of function for each user-adjustable filter
User selectable filters, parameter adjustment ranges for a notch filter
Gain
Q-value
Center frequency
Sensitivity adjustment range
Delay adjustment range
≤ 58 Hz
> 39 kHz
70 Hz – 20 kHz
2.2 ms
≥ 104 dB SPL
≥ 96 dB SPL
> 107 dB SPL
≤ 10 dB
< 5%
< 0.5%
120°
100°
130 mm (5 in) cone
19 mm (3/4 in) metal dome
3.5 kg (7.7 lb)
288 x 165 mm (11 3/8 in x 6 1/2 in) (round grille)
288 x 288 x 159 mm (11 3/8 in x 11 3/8 in x 6 1/4 in) (square grille)
100BASE-TX 1 x RJ45
130 dB SPL
AES67, Dante
3 pin Euroblock
10 kOhm, balanced
-6 dBu
24 dBu
2.9 kHz
20
Parametric notch
High frequency shelf
Low frequency shelf
Bass roll-off
Bass tilt
Treble tilt
-20...+2 dB
0.1...20
10 Hz...16 kHz
-60...0 dB
0...98 ms
