- Page 1 BW Space Pro Max Underwater Drone User Manual V 1.0...
-
Page 2: Table Of Contents
Contents Disclaimer and Safety Instructions Product List Product Overview Preparation Connecting Shut down and Retrieval Introduction of Oceaneye APP Photos and Videos Exportation Remote Controller Installation and Use of the Mechanical Arm Technical Specifications Maintenance and Care Contact Us... -
Page 3: Disclaimer And Safety Instructions
Youcan Robot (Shanghai) Co., Ltd shall not bear any responsibility. 4. Youcan Robot (Shanghai) Co., Ltd. shall not be liable for any breach of law directly or indirectly committed by our users. -
Page 4: Product List
6. When the product gives the low battery notification, you should stop using the device in time. Please do not panic in case of incidents, such as outages, broken ropes, etc. BW Space Pro Max will automatically come to the surface by buoyancy. - Page 5 BW Space Pro Max Underwater Drone Remote Controller Stand and Handle WiFi Repeater Tether Winder Charger Mechanical Arm Adapters and Mounting Bases Sealing Lubricant and Sealing Ring Adapter Cable Wrench and other Tool Kits (used when installing the tether)
-
Page 6: Product Overview
Product Overview BW Space Pro Max Protection wing Protection wing Vertical propeller Communication/ Charging interface Vertical propeller Vertical propeller Safety bolt Camera LED Light LED Light Horizontal propeller Horizontal propeller WiFi Repeater Working indicator Power switch Cable connector Battery indicator... - Page 7 Cautions 1. WiFi repeater can NOT operate in the water,so please do not put it into water. 2. WAN interface: Network interface, providing network signal for underwater live broadcast . LAN interface: can be connected to computers, notebooks and other equipment. 3.
- Page 8 【 How to install the Stand 】 1. M8*1 gasket into the M8 screw from the A side and insert it into the central hole of the tether winder; 2. Load the M8*1 gasket and bearing from the B side, and then use the M8 screw nut to lock;...
-
Page 9: Preparation
Cautions The sealing ring is the spare part of the drone connector. When the original sealing ring is damaged, please replace it in time to maintain waterproof. Preparation Charging 【 Charging of BW Space Pro Max 】... - Page 10 2. Prohibited to touch the connector front end with wet or sweaty hands; water should be dried if there is water on the connector. 3. Charge the BW Space Pro Max and WiFi Repeater every three months. 4. Make sure to use the special charger provided by Youcan Robot.
- Page 11 Please Charge Once Every Three Months 100% Download Oceaneye APP • Visit Youcan Robot website to download the Oceaneye APP ： https://www.youcanrobot.com/servicesupport Cautions • The iOS system supports version 10.3 or above, and the Android system supports Android 6.0 or above;...
-
Page 12: Connecting
Connecting Connect the equipment 1. Insert the 4-pin jack connector of the tether into the BW Space Pro Max communication port, and the round hole connector into the WiFi Repeater, and activate the WiFi Repeater power button. The indicator light of the WiFi Repeater turns green, and the connection is complete. - Page 13 3. In case of start failure, check the following things: If the device is appropriately powered; If the jack of the tether is connected to BW Space Pro Max or WiFi Repeater jack appropriately; Access the mobile phone WiFi connection interface and check to see if the...
- Page 14 【 Control system upgrade 】 To continuously optimize the operative performance of BW Space Pro Max, we will upgrade the control system of BW Space Pro Max from time to time. When you open Oceaneye APP, if the screen prompts upgrading, this indicates that the device or software is being upgraded, usually for a duration of about 1 minute.
-
Page 15: Shut Down And Retrieval 1
Space Pro Max will stop working. Retrieval Drive the drone back to the shore or pull the tether back, disconnect the tether of the BW Space Pro Max and WiFi Repeater which means a complete shutdown. Cautions When not using the drone or WiFi Repeater, Please remember to disconnect the tether, otherwise the device will remain in standby mode and the battery will continue to be consumed. -
Page 16: Introduction Of Oceaneye App 1
WiFi Repeater battery life : Display the remaining battery capacity of WiFi Repeater. BW Space Pro Max battery life : Display the remaining battery capacity of BW Space Pro Max. Settings : Enter the settings interface, configure the control mode, camera,... - Page 17 APP interface (Settings - Control Settings - Joystick Settings) Zoom :（ This feature is only available for the BW Space Pro Max Zoom ） By placing and spreading two fingers on the screen will enlarge the image;...
-
Page 18: Photos And Videos Exportation 1
1. Visit https://www.youcanrobot.com/servicesupport to download the Youcan Assistant software. 2. Connect the BW Space Pro Max and WiFi Repeater with tether, search and connect the Youcan WiFi signal on the computer (Youcan-****- 5G or Youcan-**** ， password 12345678 ） . -
Page 19: Remote Controller
Remote Controller Pause Mobile phone holder Speed Down Joystick Setting Charging indicator Low-angle shoot Left joystick Speed up Zoom in High-angle shoot （ ZOOM Model ） Right joystick Zoom out （ ZOOM Model ） Home Brightness Brightness reduction enhancement Open Close Photo Record... - Page 20 【 High-angle shoot 】 Set the pitch angle of 0 °~-45 °, the smaller the number, the larger the angle. Each time you press the button, the pitch angle increases by 5 °. 【 Pair button for phone 】 used to pair with the smart phone. (The mobile phone needs to turn on the Bluetooth function in advance).
- Page 21 Connect the Remote Controller and mobile phone Charging indicator After the quick start step is completed, follow the process below: 1. Press the Home+A button at the same time for 3-5 seconds, the Home button will light up in blue, and the remote control will be turned on. Home 2.
- Page 22 2. Please turn on the location service permission in the phone settings: 【 For Android phones 】 open "Settings", find "Applications and Services" - "Application Management" - "Oceaneye" - "Permissions", open the permissions of Oceaneye APP, and open the positioning service for Oceaneye in "Positioning". 【...
-
Page 23: Installation And Use Of The Mechanical Arm 2
2. Install the fixed base Use M4*10 (2 pieces) and M4*14 (1 piece) to fix the base on the bottom of BW Space Pro Max. 3. Install the manipulator module Install the manipulator module on the fixed seat, align it first, then fix the rear end with M3*6 screws (4 pieces), and then fix the front end with M4*12 screws and M4 nuts. - Page 24 4. Install the cable Align the cable with the power/communication ports at the bottom of the drone and the machine respectively, and tighten the nuts clockwise. How to Control the Mechanical Arm 【 APP Control 】 Click on the Oceaneye interface 【 】...
-
Page 25: Technical Specifications
2 * Horizontal, 3 * Vertical Max. Forward Thrust 6.0 kgf Max. Reverse Thrust 5.0 kgf Max. Power 156 W • BW Space Pro MAX: 4K UHD Fixed Camera Sensor 1/2.7” CMOS Effective Pixels 8 MP Aperture F2.0 Focus Length 4.0 mm... - Page 26 • BW Space Pro MAX Zoom: 4K UHD Zoom Camera Sensor 1/1.8’’ CMOS Effective Pixels 8 MP Aperture F1.4-F2.9 Focus Length 3.8mm-11.4mm Image Format JPEG Video Format Max.Video resolution 4K(3840x2160) Min. Object Dimension 0.6 m Field Angle D:141°,H:120.1°,V:64.6° SD Cards Storage 64GB •...
-
Page 27: Maintenance And Care
• Mechanical Arm Weight 1.63 lb Length 350 mm Maximum Diameter 44 mm Supply Voltage 20-25.2 v Operating Current 0.4 A (maximum) Maximum Clamping Diameter 96 mm Clamping Force 90-150 N Open and Close Time Aluminum Alloy 6061 Shell Material Aluminum Alloy 6061 (hard anodized surface) •... -
Page 28: Contact Us
Make sure the tether is Wipe the water stain securely connected to around the connector in avoid short circuit time to keep it dry Do not use heavy force Attach the cable or pulling hard on cables securely onto the and connectors drone's Safety Bolt Minors should... - Page 29 BW Space Pro Max User Manual V 1.0...
