- Page 1 Iris Transmitter/Receiver User Manual for software version 0.1.3 Updated on 11/10/2022...
-
Page 2: Table Of Contents
3.1 Setting up an audio network ..............................10 3.2 Sites with multiple audio networks ..............................12 4. LED status information 5. The Iris configurator app 6. Troubleshooting 6.1 Find the advertising name ..............................18 6.2 Find the PIN code ..............................18 6.3 Reset to default settings... - Page 3 This manual has been validated and reviewed for accuracy. The instructions and descriptions it contains are accurate for the Streamit Iris devices at the time of this manual’s production. However, later Iris devices and manuals are subject to change without notice. Streamit assumes no liability for damages incurred directly or indirectly from errors, omissions or discrepancies between Iris device and the manual.
-
Page 4: Getting Started
The Iris Transmitter (also referred to as the TX-device) can be used to broadcast high quality audio wirelessly, using DECT, to one or more Iris Receivers (also referred to as the RX-device). -
Page 5: Iris Product Range
9. Use only the supplied power adapter. Iris product range The Iris technology can be used as the base for a number of products. The scope of this manual are the products currently on offer: · Iris Transmitter · Iris Receiver... - Page 6 The current firmware does not support the GPIO related functionality. Iris Receiver The Iris Receiver also referred to as the RX-device, is connected at the playout location, very close to, or mounted on the speaker. When it comes to the appearance, one will not be able to distinguish between the RX-device and the TX-device.
-
Page 7: Applications
RX-device. Applications The Iris devices have been developed for many types of applications that require highly reliable transport of high quality audio, without cables. Any of the following applications is possible at any location (site): ·... -
Page 8: Installation
Select the correct power plug adapter for your mains socket and mount this to the base of the power adapter. Plug the power adapter to the mains outlet and plug the other side in the Iris. In the process we... -
Page 9: General Installation Notes
The analogue audio source is connected to the audio input of the . The type of cable required has an RCA connector (2x tulp male) for the Iris side, while the other end depends on the type of connector of the source device. No audio cables are included with the Iris. -
Page 10: Configuration
Configuration To be able and configure your Iris audio networks, you need to install the Iris configurator app on your mobile device. The Iris configurator is available for free and features support for Android as well as iOS. For more information and download location see §The Iris configurator app... - Page 11 Follow the instructions, and when asked, walk towards the RX-device you would like to pair with. Select the device when this shows in the list, and when asked for, enter the PIN code of the specific device (see where to find the default PIN). Iris Transmitter/Receiver...
-
Page 12: Sites With Multiple Audio Networks
Walk towards the TX-device until the device shows in the list, and select it · Access the system menu of the device, tapping the gear icon at the top-right corner of the page · Select 'Stop pairing mode' (see also §The Iris configurator app) Sites with multiple audio networks Iris Transmitter/Receiver... -
Page 13: Led Status Information
Each of the status LEDs can be switched off or light up as follows: solid, slow blink ( ), fast blink( Both LEDs must never be off while the Iris is powered up, except for the time required for the system to start up. - Page 14 TX: Paired and locked to at least one RX-device, but audio channel inactive RX: Not paired TX: Not paired RX: Pairing mode active TX: Pairing mode active RX: There is an issue with the hardware or DECT interface TX: There is an issue with the hardware or DECT interface Iris Transmitter/Receiver...
-
Page 15: The Iris Configurator App
The Iris configurator is the companion mobile app for the Iris. It enables you to configure audio networks and can be used as a remote control by the end user. The Iris configurator is available for free and features support for Android as well as iOS. - Page 16 Reboot - Reboots the device, shortly interrupting the audio connection. When rebooting a TX- device, audio will be interrupted on all RX-devices connected at the given moment. o Change PIN - Changes the PIN code for the specific device Iris Transmitter/Receiver...
- Page 17 This option requires the factory reset password, which is currently not documented. · Import sites - under development · Export sites - under development · Reset Admin password - debug/under development · Delete site database - debug · Delete site database - debug Iris Transmitter/Receiver...
-
Page 18: Troubleshooting
Find the PIN code In order for an instance of the Iris configurator to be authorized to connect to an Iris, the device PIN needs to be entered. The default PIN is printed on the sticker on the bottom of the device. When you... -
Page 19: More Information
More information In addition to this manual, the following sources are available for your reference: · Streamit support site with knowledge base: https://support.streamit.eu/ · Streamit site with additional manuals: https://www.streamit.eu Iris Transmitter/Receiver... -
Page 20: Support
For technical support regarding the Iris devices, software tools or technical documentation, please contact your dealer first. In case you are a direct customer of Streamit, please visit the support page (https://support.streamit.eu/) where you will find an option to submit a support ticket. - Page 21 © 2022 Streamit B.V.
