Summary of Contents for All In 1 Gaming Pro Series
- Page 1 Pro Series Single Monitor Mount Assembly Instructions Your pit crew is here to support you. Skype Us info@allin1gaming.com allin1gaming.com allin1gaming.com/support allin1gaming support page chat with a live agent email our team...
- Page 2 Phantom SE Monitor Mount Step 1: Rail Assembly Assembly Instructions Inset t-nuts Place 1.5x3 Brackets over t-nuts. hint: leave slightly loose. HW-CB-4590-001 PH-EXT-1515-0100 HW-FN-003-0020 HW-FN-002-0001...
- Page 3 Phantom SE Monitor Mount Step 2: Attach to Frame Assembly Instructions Repeat Step 1 for 3 remaining corners HW-FN-002-00 01 HW-FN-003-0020...
- Page 4 Phantom SE Monitor Mount Step 3: Add Cross Bar Assembly Instructions Repeat Step 1 for 3 remaining corners HW-FN-003-00 20 HW-FN-002-0001 ST-EXT-002-0675 HW-CB-4545-001 Page 2...
- Page 5 Phantom SE Monitor Mount Step 4: Add Upright Assembly Instructions REPREREPEAT STEP 1 FOR OPPOSIDE SIDEEAT STE PH-EXT-1530-0023 PH-CB-1515-01 HW-FN-002-0001 HW-FN-003-0018 Page 4...
- Page 6 Phantom SE Monitor Mount Step 5: Attach VESA Plate Assembly Instructions HW-EC-PH-1515 ST-SP-011-0001 HW-FN-002-0001 HW-EC-PH-1530 HW-FN-003-0014...
