- Page 1 MANUAL FOR INSTALLATION AND USE...
- Page 2 CONGRATULATIONS FOR YOUR NEW, ECOLOGICAL DRY TOILET! Green Toilet Lux is an composting toilet that is easy and pleasant to use and service. It is durable and will serve you for many years to come. PACKAGE CONTENT porcelain pedestal Green Toilet composting...
- Page 3 We’ r e here to help! Contact us if you have any questions about the installation of Green Toilet Lux. You can also send us pictures of the installation site. We are happy to advise on the right implementation. tel. +358 50 442 4775...
- Page 4 ASSEMBLY OF THE NON-SEPARATING PORCELAIN PEDESTAL Measure carefully the place for the porcelain pedestal in the bathroom and where the hole for the waste pipe will be. Check possible floor structures before cutting the hole. When you have measured the right place, make a hole of 210 mm to the floor. Lead the waste pipe through the hole so that about 5.5 cm is above the floor level.
- Page 5 ASSEMBLY OF THE URINE SEPARATING PEDESTAL When you have measured the right place for the pedestal, make a hole of 210 mm to the floor. Lead the waste pipe through the hole so that about 17 cm is above the floor level. 395 mm The black waste pipe (diam 20 mm) is assembled as described above.
- Page 6 Connect the black liquid hose to the outlet in the lower front of the Green Toilet and the other end to the canister (or a filter). Make a suitable outlet through the wall or the roof for the ventilation pipe.
- Page 7 USE AND MAINTENANCE OF GREEN TOILET LUX The use of Green Toilet Lux is simple: you can use it just like the water toilet, but without flushing. All toilet waste, together with the toilet paper goes down into the same composting container.
- Page 8 When you do the change, first take the liquid hose out of the container, and lift the end up so no liquid is spilled. Lift the lid of the Green Toilet container so that you can pull that out by using the wheels. Then, put the closed lid onto the full container and wheel it out to a suitable place to decompose.
