- Page 1 A C O U S T I C S BR218 Professional Sound Reinforcement Loudspeaker System Operation Instructions © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL BR218 v1.0...
-
Page 2: System Description
The DAL Control & Drive Systems provides different settings for the operation of BR218 combinations. With a gross volume of <450l the BR218 is one of the smallest high output double 18” sub/low systems with a tuning down to 38Hz. - Page 3 This symbol in connection with the signal word "Warning" indicates commands to observe product-relevant operating conditions. © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL BR218 v1.0...
-
Page 4: General Information
Such signals and devices can cause loudspeaker overload or damages and are not covered by our warranty- © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL BR218 v1.0... -
Page 5: Safety Instructions
DAL will not be liable for any damage caused in this way and will not accept any warranty or liability for consequential damage. © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL BR218 v1.0... -
Page 6: Technical Overview
(10.) Protective Front Grill with Foam Cover: Order Code: 1000520, Type DAL ASS- FGBR218) Tools required for maintenance: Srewdriver and Bits: PH2, Allan Key 5mm © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL BR218 v1.0... -
Page 7: Technical Specifications
Most DAL loudspeaker systems can be supplied for extra charge from the factory in a weatherproof (WR) or sea-weatherproof (SWR) variant. For indefinite operation outdoors in subtropical and tropical areas, the © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL BR218 v1.0... - Page 8 The BR218 is connected via 2 Speakon® NL4 sockets connected in parallel on the connector panel. The connectivity is 1+/1- for the low drivers. Connectors Pin Assignment 1+/1-: The BR218 is wired in such a way that a positive voltage at 1+ moves the cones of the low frequency transducers outwards.
- Page 9 Fixing and mounting points should be inspected frequently. BR218 - internal wiring schematic Operation of DAL BR218 There is the need of active control for the BR218 plus a dedicated power amplifier delivering RMS 5000W@4Ohm. Down below are the parameters to be adjusted for an external system controller.
-
Page 10: Note On Disposal
Applied national standards and technical specifications: DIN 18800, DIN 1055, DGUV regulation 17, BGI 810-13 Hamburg, 01.06.2018 © German Audio Engineering GmbH*An der Strusbek 1*22926 Ahrensburg – User Manual DAL BR218 v1.0...
