Summary of Contents for HIDITION GAMING T-1
- Page 1 MANUAL IN-EAR GAMING HEADSET...
-
Page 2: Table Of Contents
4 / How to Connect MMCX Connectors 17~18 P 5 / How to Disconnect MMCX Connectors 19~20 P 6 / How to Connect to PC 21~23 P 7 / How to Manage T-1 24~25 P 8 / Specification 26~29 P 9 / Precautions... -
Page 3: T-1 Package Includes 1~2 P
T-1 Package Includes T-1 and Accessories... - Page 4 IN-EAR GAMING HEADSET Earcaps S/M/L Cable tie Y adapter for PC...
-
Page 5: T-1 Parts Name 3~5 P
T-1 Parts Name... - Page 6 OVERALL VIEW T-1 Parts Name Adjustable-fit boom mic hanger MMCX Connectors Unit Microphone Head Mic Splitter Mic On/Off Switch 3.5mm 4Pole Plug...
- Page 7 DETAIL VIEW T-1 Parts Name MMCX Connectors Nozzle Unit(Left) Earcaps Unit(Right)
-
Page 8: Quick Start
Quick Start How to wear T-1 & Adjust the fit again... - Page 9 STEP . 1 Choose one of the sizes Small, Medium, Large and replace both sides of the unit. STEP . 2 Place the T-1 Adjustable-fit boom mic hanger and the cable connected to the unit over the ear hooks.
- Page 10 STEP . 3 ① Completely attach the mic splitter into the inside of the earlobes. ② Wrap the left unit around the top of the ear hook. ③ Insert the earbud into the ear in the over-ear-wearing method. STEP . 4 ①...
- Page 11 STEP . 5 ① Bend the Adjustable-fit boom microphone hanger upward so that the microphone head faces the mouth, in the position of the 'tragus' of the ear, as shown in the picture. STEP . 6 ① Adjust the Adjustable-fit boom microphone hanger and ②...
- Page 12 Wrap the right unit around the upper part of the earlobe and insert it into the ear canal using the over-ear-wearing method STEP . 8 Plug T-1's cables into your gaming device, and it's time for you to enjoy T-1's HIGHEND GAMING SOUND.
- Page 13 *Tips HOLD *Tips With the microphone splitter fixed, bend the Adjustable-fit boom- microphone hanger outward (the side that adheres closely to the body) to set the microphone splitter more tightly to the ear.
- Page 14 Quick Start Adjust the fit again Spread the Adjustable-fit boom- STEP . 1 microphone hanger like the above image. Proceed again STEP . 2 from the 2nd to 6th steps of "Quick Start." Warning - Do not bend or twist the mic head, mic splitter or mic Cable of the cable firmly.
-
Page 15: How To Connect Mmcx Connectors
How to Connect MMCX Connectors How to connect MMCX connectors with Unit... - Page 16 STEP . 1 Remove the unit from the sponge. STEP . 2 Distinguish the right and left of the unit. There is a dot on the top of the MMCX connectorof the left unit.
- Page 17 STEP . 3 BLUE After distinguish the left and right unit, Connect the MMCX connector with the blue ring to the left unit. Connect the MMCX connector with the red ring to the right unit. STEP . 4 Hold the unit and MMCX connector with both hands in the closest position and connect them.
- Page 18 STEP . 5 The unit and MMCX connector are pushed together until they make a sound indicating they are connected. 주의 STEP . 6 Make sure differentiate the Left and Right sides BLUE Check that the left MMCX connector is properly connected to the left unit and the right MMCX connector is properly connected to the right unit.
-
Page 19: How To Disconnect Mmcx Connectors
How to Disconnect MMCX Connectors How to Disconnect MMCX connectors with Unit... - Page 20 STEP . 1 Hold the unit and its MMCX Connector with both of your hands. (As of close as possible to its seams) STEP . 2 Pull away cables from the connectors in a parallel motion.
-
Page 21: How To Connect To Pc
How to Connect to PC How to connect using a Y adaptor... - Page 22 STEP . 1 Insert the Y adapter for PC into the 4-pole 3.5mm plug terminal of T-1. STEP . 2 Connect the microphone input and sound output terminals separately.
-
Page 23: How To Manage
How to Manage T-1 How to store and clean... - Page 24 How to store products Please wrap the Adjustable-fit boom microphone hanger in a wide circle so that the shape does not collapse. Tip: If you wrap it around a cable tie and store it, you can prevent tangled problems with other products.
- Page 25 If a nozzle is clogged with foreign substances, turn it upside down and shake it off with a brush. Warning: Do not use highly volatile materials when cleaning the product. STEP 2 After using T-1, always keep the ear tips and nozzles clean.
-
Page 26: Specification
Specification T-1 Specification... - Page 27 T-1 Specification Transducer One single balanced armature driver Frequency response 20Hz ~ 17kHz Impedance 58 Ohms (1kHz) Sensitivity 103dB / 1mW (1kHz) Plug 3.5mm 4Pole Lenght / Weight 1.35m / 24g Feature Adjustable-fit boom microphone, MIC ON/OFF switch controller, MMCX connectors...
-
Page 28: Precautions
Precautions Precautions in Using Device... - Page 29 T-1 In-Ear Gaming Headset Precautions in Using Device Precautions for moisturet and fires · Do not use, store, or leave it in a place full of moisture, dust, smoke or vapor, a place where fire occurs, where direct sunlight shines, or where it is hot inside the vehicle.
- Page 30 T-1 In-Ear Gaming Headset Precautions in Using Device Precautions for volume adjustment · Listening to a high volume can affect your hearing. Precautions when wearing it · Wear earbuds and cables firmly. Otherwise, earbuds and cables may be separated and stuck in the ear, causing damage or disease.
- Page 31 If you occasionally develop skin rashes or hives, stop using them. Trademark · The Hidition Gaming logo is a registered trademark of Makina International Inc. · All other trademarks and trade names are trademarks or trade names of their owners.
- Page 32 © 2023 Makina Co,. Ltd.
