- Page 1 MANUAL GAMING IN-EAR HEADSET...
- Page 2 © 2021 Makina international Inc.
-
Page 3: Table Of Contents
Contents 01 Product Includes 3 ~ 5 02 Package Includes 6 ~ 7 03 Quick Start 8 ~ 12 04 How to manage products 13 ~ 15 05 Audio and MIC Volume Setting 16 ~ 17 06 How to manage products 18 ~ 19 07 Specifications 20 ~ 21... -
Page 4: Product Includes
Product Includes... - Page 5 MMCX Connector (M) Adjustable-fit Boom-MIC Hanger Unit MIC Spliter MIC Head ON/OFF Switch GAMING IN-EAR HEADSET 3.5mm 4-Pole Plug...
- Page 6 MMCX Connector (M) Nozzle MMCX Connector (F) Earcap Left Unit Right Unit...
-
Page 7: Package Includes
Package Includes... - Page 8 GAMING IN-EAR HEADSET Earcaps Y adapter Cable tie S/M/L for PC...
-
Page 9: Quick Start
Quick Start How to wear T-1... - Page 10 Locate the cable (connected with adjustable boom mic + unit) around your ears. ③ ② ① With the mic splitter tightly sealed, ② rotate T-1 from the top of your ears and ③ insert the unit into your ears with the over-ear method. ①...
- Page 11 ② ① ① With the mic splitter tightly sealed, ② bend the adjustable boom mic hangers facing down. Locate the Adjustable boom mice hanger onto your tragus and bend it upwards. (So the mic's head would face your mouth) ① Adjust the adjustable-fit boom mic hangers ①...
- Page 12 Rotate the right side unit of T-1 and insert the device into your earholes. (Over-ear method) Plug T-1's cables into your gaming device, and it's time for you to enjoy T-1's HIGHEND GAMING SOUND. *Tips HOLD With the microphone splitter fixed, bend the Adjustable-fit boom microphone hanger outward...
- Page 13 Adjust the fit again Spread the Adjustable-fit boom microphone hanger like the right image. Proceed again from the 2nd to 6th steps of "Quick Start." If the wearing is not perfect, refer to the “Tips”(Page12) section.
- Page 14 How to use MMCX Connetors...
- Page 15 Cable Disassembly Hold the unit and its MMCX Connector (M) Housing with both of your hands. (As of close as possible to its seams) 2. Pull away cables from the connectors in a parallel motion.
- Page 16 Cable Replacement Sort out the Left and Right sides of the unit and the MMCX Connector Housing. Tightly seal the unit to the MMCX until you hear it click. Warning Make sure you differentiate the Left and Right sides before its reassembly/replacement.
-
Page 17: Audio And Mic Volume Setting
Audio and MIC Volume Setting... - Page 18 When using it in a PC environment 1. Insert the Y adapter for PC into the 4-pole 3.5mm plug terminal of T-1. 2. Connect the microphone input and sound output terminals separately. When there's not enough volume to input the microphone in a PC environment Microphone Boost +10.0 dB...
- Page 19 How to manage products...
- Page 20 How to clean and manage nozzles. If a nozzle is clogged with After using T-1, always keep foreign substances, turn it upside down the ear tips and nozzles clean. and shake it off with a brush.
- Page 21 Specifications...
-
Page 22: Specifications
Specifications Gaming In-Ear Headset T-1 Transducer One single vanlanced armature driver Frequency response 20Hz ~ 17kHz Impedance 58 Ohms (1kHz) Sensitivity 103dB / 1mw (1kHz) Plug 3.5mm 4Pole Feature adjustavble-fit boom microphone, MIC ON/OFF switch controller, MMCX connectors Sound-Signature Flat, Monitoring... -
Page 23: Precautions In Using Device
Precautions in Using Device... - Page 24 If you occasionally develop skin rashes or hives, stop using them. Trademark · The Hidition Gaming logo is a registered trademark of Makina International Inc. · All other trademarks and trade names are trademarks or trade names of their owners.
