- Page 1 All manuals and user guides at all-guides.com How to replace PULLEY BEARINGS on BLACK DEVIL...
- Page 2 All manuals and user guides at all-guides.com STEP 1. take off the seeger from Step 2. position pulley on press pulley for ejecting the bearings Should you not have a press you can use an ejector...
- Page 3 All manuals and user guides at all-guides.com STEP 3. insert a tool to press out Step 4. cam of pulley with the cam of pulley bearings ejected from pulley...
- Page 4 All manuals and user guides at all-guides.com STEP 5. take off seeger on STEP 6. with a long tool eject bearings bearings from cam of pulley...
- Page 5 All manuals and user guides at all-guides.com STEP 8. using a cylinder shape core STEP 7. bearings ejection on dry pressing install the first press bearings...
- Page 6 All manuals and user guides at all-guides.com STEP 9. insert fist bearings on cylinder shape core dry pressing STEP 10. press it down cam of pulley...
- Page 7 All manuals and user guides at all-guides.com STEP 11. insert the washer in between bearings, have STEP 12. press second bearing using previously took off following again steps 8-9-10...
- Page 8 All manuals and user guides at all-guides.com STEP 12. install the seeger back on STEP 13. insert the cam of pulley with top of bearings bearings on pulley...
- Page 9 All manuals and user guides at all-guides.com STEP 13. insert pulley seeger back on.
