- Page 1 SCION SC01.7060 SCION SC05.9000F HDMI Extender over Fibre 4K/60Hz, 4:4:4 Operating Instructions Version 1.0 www.scion-tech.co.uk sales@scion-tech.co.uk Tel: +44 (0) 1635 862484...
-
Page 2: Table Of Contents
Scion Tech SC05.9000F User Manual Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
User Manual 1.0 Introduction The SC05.9000F extends the distance between the HDMI source and display using a single or multi mode fibre up to 10km. Uncompressed 4K/60Hz video is transmitted without delay or signal degradation. This extender supports full duplex RS232, embedded/de-embedded audio and bi-directional infrared. The units are only 18mm in height making them a perfect solution for installing behind any display. -
Page 4: Specifications
Scion Tech SC05.9000F User Manual 4.0 Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 Video Bandwidth 18Gbps Video Resolution Up to 4K@60Hz 4:4:4 HDBaseT Bandwidth 16Gbps on main and 2Gbps on return link HDR, HDR10, HDR10+, Dolby Vision, HLG... -
Page 5: Controls And Functions
Scion Tech SC05.9000F User Manual 5.0 Controls and Functions 5.1 Transmitter Panel HDMI Service Line Loop Power Fibre EDID HDMI IR In IR Out DC 5V HDMI Out Line In HDMI In Name Function / Description Power LED Illuminates when powered on... -
Page 6: Receiver Panel
Scion Tech SC05.9000F User Manual 5.2 Receiver Panel Service Power Fibre HDMI IR In IR Out DC 5V Line In HDMI Out Name Function / Description Power LED Illuminates when powered on Fibre LED Illuminates when a fibre connection is made between the TX and RX HDMI LED HDMI LED’s illuminate when a display is detected... -
Page 7: Ir Pin Connections
Scion Tech SC05.9000F User Manual 5.3 IR Pin Connections IR Blaster IR Receiver + Positive IR Blaster - Negative IR Signal IR Receiver Ground Power 12V Note: When the angle between the IR receiver and the remote control is +/- 45 degrees, the transmission distance is 0-5 meters. -
Page 8: Application Drawing
Scion Tech SC05.9000F User Manual 6.0 Application Drawing IR Receiver IR Blaster HDMI Service Line Loop Power Fibre EDID HDMI IR In IR Out Transmitter 1 5 * $ " DC 5V Line In HDMI Out HDMI In Power Supply...
