- Page 1 INSTALLATION AND OPERATING INSTRUCTIONS for all VEFSA Freezer Models 809-208A Rev. 11/23/2022 SEE BACK COVER FOR 3779 CHAMPION BLVD, WINSTON-SALEM, NC 27105 WARRANTY REGISTRATION Phone: (888) 845-9800 | Fax: (800) 253-5168 | Web: victoryrefrigeration.com...
-
Page 2: Table Of Contents
User Manual for VEFSA Freezers Victory WELCOME Thank you for purchasing a Victory cabinet. This series instructions before installing or using your unit. If you has passed our strict quality control inspection and meets have any questions, Please call our Technical Service the high standards set by Victory Refrigeration! You have Department at (800) 684-1199. -
Page 3: Safety
R290 equipment. • Clean a dirty condenser with a sharp object. • Use ONLY Victory factory service parts. Use of non • Store gasoline, kerosene or any other flammable OEM parts can be dangerous because of the design material near the cabinet. -
Page 4: Important Information
User Manual for VEFSA Freezers Victory IMPORTANT INFORMATION This unit is intended to be used in a commercial application. That includes bars and restaurants. If installed in a residence some commercial service companies may not be able to service it on site. -
Page 5: Product Information
User Manual for VEFSA Freezers Victory PRODUCT INFORMATION Cabinet Dimensions Half or Full Glass or Full Load Power Cord Refrigerant Type / Model w x d x h (Inches) Door Solid Door Amps Plug (NEMA) Charge (g) / Charge (oz) -
Page 6: Clearance And Placement
User Manual for VEFSA Freezers Victory CLEARANCE AND PLACEMENT Placement Consider the following when selecting a location for your freezer: Clearance: • 12 in. at the top • 3.0 in. at the rear, • 0.0 in. at the left side •... -
Page 7: Unpacking And Set Up
User Manual for VEFSA Freezers Victory UNPACKING AND SET UP Carefully inspect the shipping carton for damage. This is the only time that shipping damage may be claimed. If damage is suspected, open the carton immediately and, if there is damage, retain the carton and contact the shipper to make a claim. -
Page 8: Shelf Installation
4. Install all remaining clips. manner. Contact Victory customer service if fewer shelves or a different configuration to ensure shelf 5. Install shelves onto clips with the product retention overloading will not occur. -
Page 9: Electrical
5-15P plug or a 5-20P plug. machine to confirm the voltage and per the dataplate use the correct fuses or HACR circuit breakers. Victory recommends using a HUBBELL Model Number which have a trip limit of 4 to 6 mA. To avoid this... -
Page 10: Using The Unit
01 2 3 ÿ 56 7 8 6 9 ÿ 3 ÿ ÿ 3 2 2 2 3 1 ÿ 2 2 3 6 2 3 User Manual for VEFSA Freezers Victory ./0 12ÿ 456ÿ .10 4 USING THE UNIT 78 9 : ;... -
Page 11: Sequence Of Operations Freezer
User Manual for VEFSA Freezers Victory SEQUENCE OF OPERATIONS FREEZER The freezer operates based on the air temperature measured by the probe located at the return air. CONTROLLER CONTROLLER COMPONENT OPERATION OPERATION ACTION ACTION Compressor turns Compressor turns The Compressor Contact... - Page 12 User Manual for VEFSA Freezers Victory Condition Cabinet Temp > Set point + 2.5 ON or OFF Cabinet Temperature <= Set point - 2.5 ON or OFF Defrost ON or OFF Electronic Controller DEFROST (ESC) SELECT (OK) DOWN Control Panel Display...
- Page 13 User Manual for VEFSA Freezers Victory Note: When the controller is in a Standby Mode, a blue dot will be displayed as shown here. To switch out of Standby Mode, push and release the Defrost button. Control Panel Connections Changing the Set point Rev.
- Page 14 User Manual for VEFSA Freezers Victory () * + , ÿ . / ÿ 0 1 0 2 3ÿ 4 5 6 1 7 8 9 : ; ÿ < 9 34 8 ÿ 0 2 4 ÿ 9 ; ÿ = 2 : > 2 4 8 8 ÿ ? @A @ÿ / : 1 C 4 2 ÿ : / ÿ < D 4 ÿ = 0 2 0 34 < 4 2 ÿ < 0 E 1 4 F G ÿ < D 4 ÿ 0 1 0 2 3ÿ 9 8 ÿ ; : < ÿ 8 9 > ; 0 1 4 C H ÿ...
-
Page 15: Cleaning And Maintenance
User Manual for VEFSA Freezers Victory CLEANING AND MAINTENANCE Cleaning Schedule: Cabinet Condenser coil Gaskets Routine maintenance Daily wipe down Quarterly cleaning Daily inspection, check Annually that hinges are tight to Weekly interior the cabinet. Daily Exterior Cleaning It is much easier to clean on a regular basis than to have to remove stains once they have built up. -
Page 16: Condenser Cleaning
User Manual for VEFSA Freezers Victory CONDENSER CLEANING Keeping the condenser coil clean is critical to efficient operation. 1. Unplug unit from power supply. Rotating fan blade can cause CAUTION personal injury. Unplug unit from power supply before beginning to clean... -
Page 17: Methods For Cleaning Stainless Steel
User Manual for VEFSA Freezers Victory METHODS FOR CLEANING STAINLESS STEEL Cleaning Needed Cleaning Agent Method of Application Affect on Finish Satisfactory for use on all Areal 20, Lac-O-Nu, Lumin Wash Rub with cloth as directed finishes. Smears and fingerprints O’Cedar Cream Polish, Stainless... -
Page 18: Help
User Manual for VEFSA Freezers Victory HELP Trouble Diagnosis for the User Malfunction Possible Cause Likely Solution Connect to proper voltage circuit Replace Unit not plugged in. fuse or reset breaker. No cooling - unit is silent Fuse or circuit breaker tripped. -
Page 19: For The Service Tech - R290
User Manual for VEFSA Freezers Victory FOR THE SERVICE TECH - R290 Refrigeration service should only be attempted by a trained trade professional certified to work on R290 systems. Here are some critical service items. Other Information: This list does not qualify anyone to service the unit. It is a Evacuation: It is critical that a refrigeration system be reminder and checklist for the service tech. -
Page 20: For The Service Tech - Wiring Diagrams
User Manual for VEFSA Freezers Victory FOR THE SERVICE TECH - WIRING DIAGRAM FOR ONE SYSTEM MODELS 115VAC 60 HZ *SEE CONTROLLER DETAIL COMPRESSOR DETAIL CONDENSER FAN START RELAY S.C. COMP R.C. *SEE CONTROLLER DETAIL FACE HEATER (1) DOOR HEATER (1) - Page 21 User Manual for VEFSA Freezers Victory FOR THE SERVICE TECH - WIRING DIAGRAM FOR TWO SYSTEM MODELS 115VAC 60 HZ *SEE CONTROLLER DETAIL COMPRESSOR DETAIL CONDENSER FAN START RELAY S.C. COMP R.C. *SEE CONTROLLER DETAIL COMPRESSOR DETAIL CONDENSER FAN START RELAY S.C.
-
Page 22: Replacement Parts
01 2 3 ÿ 56 7 8 6 9 ÿ 3 ÿ ÿ 2 3 2 3 6 3 1 ÿ 3 User Manual for VEFSA Freezers Victory '()* +,(-(./ÿ )+'/1ÿ 23'ÿ 4('1+5 6 75 175 8,ÿ 5 ÿ ,+9: .(/ REPLACEMENT PARTS FOR VEFSA-1D-SD-HC - CABINET ;... - Page 23 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-1D-SD-HC - ASSEMBLIES Rev. 11/22 Victory...
- Page 24 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-1D-SD-HC - FREEZER SYSTEM 501-186D-02 EVAP FAN (1) 305-570D EVAP COIL (1) 510-022D-03 DEFROST HEATER (1) 305-449D CONDENSER COIL (1) 501-186D-01 CONDENSER FAN (1) V002838 CONDENSATE PAN (1) 312-215D COMPRESSOR (1) Victory Rev.
- Page 25 01 2 3 ÿ 56 78 6 9 ÿ 3 ÿ ÿ 2 3 2 3 6 3 1 ÿ 3 User Manual for VEFSA Freezers Victory '()* +,(-(./ÿ )+'/1ÿ 23'ÿ 4('1+5 6 75 875 8,ÿ 5 ÿ ,+9: .(/ REPLACEMENT PARTS FOR VEFSA-1D-HD-HC - CABINET ;...
- Page 26 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-1D-HD-HC - ASSEMBLIES Victory Rev. 11/22...
- Page 27 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-1D-HD-HC - FREEZER SYSTEM 501-186D-02 EVAP FAN (1) 305-570D EVAP COIL (1) 510-022D-03 DEFROST HEATER (1) 305-449D CONDENSER COIL (1) 501-186D-01 CONDENSER FAN (1) V002838 CONDENSATE PAN (1) 312-215D COMPRESSOR (1) Rev.
- Page 28 User Manual for VEFSA Freezers Victory 01 2 3 ÿ 56 7 8 6 9 ÿ 3 ÿ ÿ 2 3 2 3 6 3 1 ÿ 3 REPLACEMENT PARTS FOR VEFSA-1D-GD-HC - CABINET &'() *+','-.ÿ...
- Page 29 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-1D-GD-HC - ASSEMBLIES DOOR ASSEMBLY (PART # 40B48-474D-01) 710-004A STRIKE-LIGHT SWITCH C/K DOOR (1) 712-047D-01 DOOR GASKET (1) 50597111 LOCK STRIKE (1) -------------------- SHIM – LOCK STRIKE – NOT SHOWN, NOT SOLD SEPARATELY (1) -------------------- DOOR HANDLE –...
- Page 30 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-1D-GD-HC - FREEZER SYSTEM 501-186D-02 EVAP FAN (1) 305-570D EVAP COIL (1) 510-022D-03 DEFROST HEATER (1) 305-449D CONDENSER COIL (1) 501-186D-01 CONDENSER FAN (1) V002838 CONDENSATE PAN (1) 312-215D COMPRESSOR (1) % &...
- Page 31 01 2 3 ÿ 56 7 8 6 9 ÿ 3 ÿ ÿ 2 3 2 3 6 3 1 ÿ 3 Victory REPLACEMENT PARTS FOR VEFSA-1D-HG-HC - CABINET '()* +,(-(./ÿ...
- Page 32 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-1D-HG-HC - ASSEMBLIES RIGHT HAND TOP DOOR ASSEMBLY (PART # 40B48-474D-03) 710-004A STRIKE-LIGHT SWITCH C/K DOOR (1) 712-047D-02 DOOR GASKET (1) 50597111 LOCK STRIKE (1) -------------------- SHIM – LOCK STRIKE – NOT SHOWN, NOT SOLD SEPARATELY (1) -------------------- DOOR HANDLE –...
- Page 33 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-1D-HG-HC - FREEZER SYSTEM 501-186D-02 EVAP FAN (1) 305-570D EVAP COIL (1) 510-022D-03 DEFROST HEATER (1) 305-449D CONDENSER COIL (1) 501-186D-01 CONDENSER FAN (1) V002838 CONDENSATE PAN (1) 312-215D COMPRESSOR (1) Rev.
- Page 34 User Manual for VEFSA Freezers Victory 01 2 3 ÿ 56 78 6 9 ÿ 3 ÿ ÿ 2 3 2 3 6 3 1 ÿ 3 REPLACEMENT PARTS FOR VEFSA-2D-SD-HC - CABINET '()* +,(-(./ÿ...
- Page 35 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-2D-SD-HC - ASSEMBLIES Rev. 11/22 Victory...
- Page 36 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-2D-SD-HC - FREEZER SYSTEM 501-186D-02 EVAP FAN (1) 305-570D EVAP COIL (1) 510-022D-03 DEFROST HEATER 305-449D CONDENSER COIL (1) 501-186D-01 CONDENSER FAN (1) V002838 CONDENSATE PAN (1) 312-204D COMPRESSOR (1) •...
- Page 37 01 2 3 ÿ 56 78 6 9 ÿ 3 ÿ ÿ 2 3 2 3 6 3 1 ÿ 3 User Manual for VEFSA Freezers Victory '()* +,(-(./ÿ )+'/1ÿ 23'ÿ 4('1+5 675 875 8,ÿ 5 ÿ ,+9: .(/ REPLACEMENT PARTS FOR VEFSA-2D-HD-HC - CABINET ;...
- Page 38 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-2D-HD-HC - ASSEMBLIES Victory Rev. 11/22...
- Page 39 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-2D-HD-HC - FREEZER SYSTEM 501-186D-02 EVAP FAN (1) 305-570D EVAP COIL (1) 510-022D-03 DEFROST HEATER (1) 305-449D CONDENSER COIL (1) 501-186D-01 CONDENSER FAN (1) V002838 CONDENSATE PAN (1) 312-215D COMPRESSOR (1) Rev.
- Page 40 User Manual for VEFSA Freezers Victory User Manual for VERSA Refrigerators Victory REPLACEMENT PARTS FOR VEFSA-2D-GD-HC - CABINET REPLACEMENT PARTS FOR VERSA-2D-GD-HC - CABINET 46A33-911D-15 SHELL END TOP (2) 46A33-911D-15 SHELL END TOP (2) 50A36-242D-19 INSTRUMENT PANEL (1) 50A36-242D-19 INSTRUMENT PANEL (1)
- Page 41 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-2D-GD-HC - ASSEMBLIES LEFT HAND DOOR ASSEMBLY (PART #40B48-474D-02) 710-004A STRIKE-LIGHT SWITCH C/K DOOR (1) 712-047D-01 DOOR GASKET (1) 50597111 LOCK STRIKE (1) -------------------- SHIM – LOCK STRIKE – NOT SHOWN, NOT SOLD SEPARATELY (1) -------------------- DOOR HANDLE –...
- Page 42 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-2D-GD-HC - FREEZER SYSTEM **TWO DOOR UNITS WITH GLASS DOORS HAVE TWO SEPARATE FREEZER SYSTEMS** 501-186D-02 EVAP FAN (1) 305-570D EVAP COIL (1) 510-022D-03 DEFROST HEATER (1) 305-449D CONDENSER COIL (1)
- Page 43 User Manual for VERSA Refrigerators Victory User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VERSA-2D-HG-HC - CABINET REPLACEMENT PARTS FOR VEFSA-2D-HG-HC - CABINET 46A33-911D-15 SHELL END TOP (2) 46A33-911D-15 SHELL END TOP (2) 50A36-242D-19 INSTRUMENT PANEL (1) 50A36-242D-19 INSTRUMENT PANEL (1)
- Page 44 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-2D-HG-HC - ASSEMBLIES LEFT HAND TOP DOOR ASSEMBLY (PART # 40B48-474D-05) 710-004A STRIKE-LIGHT SWITCH C/K DOOR (1) 712-047D-02 DOOR GASKET (1) 50597111 LOCK STRIKE (1) -------------------- SHIM – LOCK STRIKE – NOT SHOWN, NOT SOLD SEPARATELY (1) -------------------- DOOR HANDLE –...
- Page 45 User Manual for VEFSA Freezers Victory REPLACEMENT PARTS FOR VEFSA-2D-HG-HC - FREEZER SYSTEM **TWO DOOR UNITS WITH GLASS DOORS HAVE TWO SEPARATE FREEZER SYSTEMS** 501-186D-02 EVAP FAN (1) 305-570D EVAP COIL (1) 510-022D-03 DEFROST HEATER (1) 305-449D CONDENSER COIL (1)
-
Page 46: Limited Warranty
THREE (3) YEAR PARTS AND LABOR WARRANTY: Also, this extended compressor-part only warranty does NOT apply to any electrical controls, condenser, evaporator, Victory Corporation warrants to the original purchaser of fan motors, overload switch, starting relay, capacitors, Victory branded equipment, including all parts thereof,... -
Page 47: Limited Warranty (Continued)
With the exception of Blast Chillers product is designed for LIMITATION OF LIABILITY: maintaining temperature and not bringing food to a desired Victory Corporation or their affiliates shall not be liable for temperature therefore cannot be held responsible for this any indirect, incidental, special or consequential damages, function under warranty. - Page 48 Register your product online at victoryrefrigeration.com/parts-service or fill out and mail the form below. Cabinet Model Number: _____________________________________________ Date Of Installation: _________________ Cabinet Serial Number: _____________________________________________ Location Of Product Business Name: ____________________________________________________ Business Street: ____________________________________________________ Business City: ____________________________________ State: _________ Postal Code:___________ Mail to: Victory, 3779 Champion Blvd, Winston-Salem, NC 27105 Rev. 11/22...
