- Page 1 User manual SLM-BAR24 Please read the instructions carefully before use...
- Page 2 TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3-4 Technical Specifications…………………………………………………………………………4 Control Menu ………………………………………………………………………………………5 DMX Channels ……………………………………………………………………………………6 Trouble Shooting………………………………………………………………………………….7 Fixture Cleaning………………………………………………………… ………………………7 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &...
- Page 3 1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •...
- Page 4 fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. •The equipment must be fixed by professionals.
- Page 5 3.Control Menu Function Instruction Show DMX Address（001—512） d001 32 Channels mode DMX Address（001—512） A001 12 Channels mode Red Dimming, From dark to light R255 Green Dimming, From dark to light G255 Blue Dimming, From dark to light B255 White Dimming, From dark to light U255 (01-08) 8Color output FH01...
- Page 6 4.DMX Channels 12 Channels Mode: Channel DMX Value Function 000-255 Dimmer RGBW Total Dimming, From dark to light 000-255 Red dimming,From dark to light 000-255 Green Green dimming,From dark to light 000-255 Blue Blue dimming,From dark to light 000-255 White White dimming,From dark to light 000-255 Strobe...
- Page 7 5.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
