- Page 1 User manual MINI 740 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions………………………………………………………………………………3-4 Technical Specifications……………………………………………………………………………4 Control Menu …………………………………………………………………………………………5 DMX Channels ……………………………………………………………………………………6-7 Dimension ……………………………………………………………………………………………8 Trouble Shooting……………………………………………………………………………………9 Fixture Cleaning………………………………………………………… …………………………9 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture. -
Page 5: Control Menu
3.Control Menu Menu Operation Main Menu 2nd Menu 3rd Menu 4th Menu DMX Address 000 - 512 STD / HSI Dmx Mode Run Mode DMX / Host / Sound Fixture Pan Invert Close / Open Tilt Invert Close / Open Sound Control 1 -- 30 000 - 255... -
Page 6: Dmx Channels
4.DMX Channels 12 CH Mode Channel Features value Function 0--255 Pan movement control Pan Fine 0--255 Pan fine control Tilt 0--255 Tilt movement control Tilt Fine 0--255 Tilt fine control Pan/Tilt speed 0--255 Speed from fast to slow Dimmer 0--255 0-100 linear dimmer from dark to bright 0--3 Close... - Page 7 0--3 Close 4--103 Regular Strobe, Slow To Fast 104--107 Open 108--207 Pulse, Slow To Fast Strobe 208--212 Open 213--225 Random Slow Strobe 226--238 Random Middle Speed Strobe 239--251 Random Fast Strobe 252--255 Open 0--255 1-100% Red linear dimmer from dark to bright 0--255 1-100% Green linear dimmer from dark to bright CH10...
-
Page 8: Dimension
5.Dimension... -
Page 9: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
