Numark NDX200 Service Manual page 8

ERP Code Part Name
3.01.NDX200.003DR Power PCB
3.25.05.0010R00JR SMT Resistor
3.26.05.04.103MFR SMT Resistor
3.26.05.05.104MFR SMT Capacitor
3.23.04.220D.X0812
Electrolytic Capacitor
R
3.23.04.470C.X0812R
Electrolytic Capacitor
3.23.05.682D.X1835R
Electrolytic Capacitor
3.23.05.102C.X0816R
Electrolytic Capacitor
3.52.06.006R Wiring
3.52.06.008R Wiring
3.06.02.IN4007R DIP Diode
DIP Diode
3.06.02.SR260R
3.02.KA7808.00R DIP IC
3.02.KA7908.00R DIP IC
3.50.03.03P.H0R Connector
3.59.B.05P160.H22R Wiring
ERP Code Part Name
3.01.NDX200.005DR Light PCB
3.07.2R54SD.06R LED
3.61.A.02P100.W28R Wiring
ERP Code Part Name
3.01.NDX200.006DR Light PCB
3.25.05.0470R00JR SMD Resistor
3.07.5R3SD0.24R LED
3.50.02.02P.W0R Connector
NO NAME
ERP Code Part Name
3.01.NDX400.009CR PCB
3.26.05.02.101JFR SMT Capacitor
3.26.05.03.102KFR SMT Capacitor
3.26.05.02.471KFR SMT Capacitor
3.26.05.05.104MFR SMT Capacitor
3.26.05.03.122KFR SMT Capacitor
3.26.05.05.224MDR SMT Capacitor
3.26.05.03.272KFR SMT Capacitor
3.26.05.03.822KFR SMT Capacitor
3.26.05.03.332KFR SMT Capacitor
3.26.05.02.391JFR SMT Capacitor
3.26.05.02.681JFR SMT Capacitor
3.26.05.04.103MFR SMT Capacitor
3.26.05.06.105MDR SMT Capacitor
3.26.05.01.22P0JFR SMT Capacitor
3.11.06.1D5K.05R SMT Inductor
拟制： 校对：
NDX200 BOM
Specification
NDX200PCB-03D 25×100mm
10R 0805 ±5％
103/50V 0805 ±20％
104/50V 0805 ±20%
220U/25V Φ8×12 +80%-20% 105℃
470uF/16V Φ8×12 +80%-20% 105℃
6800u/25V Φ18×35 +80%-20% 105℃
1000u/16V Φ 8×16 +80%-20% 105℃
6mm Φ0.6
8mm Φ0.6
IN4007 DO-41
SR260 DO-15
KA7808 TO-220 F
KA7908 TO-220 F
3P*2.54
5P*150MM 24＃
Specification
NDX200PCB-05D 20.75×28mm 单面 LPCS 1 94VO
2R54SD-06 LED2*5 red
2P*100MM 28#
Specification
140×140mm 单面 LPCS 1 94VO
NDX200PCB-06D
470R 0805 ±5％
CL-5R3SD-24(542) Red
2P*2.0
MODE
Specification
NDX200/400 PCB-09C Servo (140.8*92*PCS 1 FR-4 dual-layer
101/50V 0805 ±5％
102/50V 0805 ±10％
471/50V 0805 ±10％
104/50V 0805 ±20％
122/50V 0805 ±10％
224/25V 0805 ±20％
272/50V 0805 ±10％
822/50V 0805 ±10％
332/50V 0805 ±10％
390pF/50V 0805 ±5％
680pF/50V 0805 ±5％
103/50V 0805 ±20％
105/25V 0805 ±20％
22pF/50V 0805 ±5％
1.5K@100MHz 0805 ±5％
审核： 日期：12/16/2009
Unit Position
Q'ty
PCS 1 94VO
PCS 2 R3 R4
PCS 4 C1 C2 C3
PCS 2 C9 C10
PCS 1 C5
PCS 1 C7
PCS 1 C6
PCS 1 C8
PCS 1 J1
PCS 1 J2
PCS 2 D1 D2
PCS 2 D3 D4
PCS 1 IC2
PCS 1 IC1
PCS 1 CN1
PCS 1 CN2
Unit Position
Q'ty
PCS 1 LED1001
PCS 1 CNP1
Position
Unit Q'ty
PCS 5 R1032 R1031R1030R1029 R1028
PCS 5 LED1003 LED1005
PCS 1 CN5
UNIT OTY LOCATION
Position
Unit Q'ty
PCS 6 C250 C251 C248 C249 C255 C256
PCS 2 C246 C247
PCS 2 C253 C254
C100 C115 C116 C180 C197 C200 C201 C186
C117 C119 C122 C123 C151 C152 C153 C171
PCS 40 C154 C155 C156 C157 C158 C159 C160 C199
C161 C162 C163 C165 C166 C167 C169 C170
C195 C226 C179 C202 C198 C252
PCS 1 C177
PCS 1 C196
PCS 1 C181
PCS 1 C182
PCS 2 C243 C244
PCS 1 C176
PCS 1 C183
PCS 2 C241 C242
PCS 5 C189 C190 C191 C231 C232
PCS 6 C175 C178 C187 C188 C193 C194
BD108 BD109BD117BD103 BD104 BD105BD106BD107
PCS 17
BD114 BD116BD118BD110 BD111 BD122BD123BD124
BD125
R217 R227 R248 R250 R252 R300 R301 R214
C4
LED1016 LED1017
REMARK
第2页，共8页
LED1018
