Numark NDX200 Service Manual page 10

3.05.1015R SMT Transistor
3.05.RN1442LAR SMT Transistor
SMT IC
3.03.AIC809.00R
3.03.TCC8600.00R SMT IC
3.03.M1742.00R SMT IC
3.02.BA033T.00R DIP IC
3.02.KA7805.00R DIP IC
3.03.39VF800.00R SMT IC
3.03.HY57V.00R SMT IC
3.03.BU9543.00R SMT IC
3.09.A.12MHZR
Crystal Oscillator
3.09.A.16M9344R
Crystal Oscillator
3.30.01.CKX3502P05R MIC
3.29.AV28414.01R Socket
3.50.03.04P.H0R Connector
3.50.02.08P.H0R Connector
3.50.02.05P.H0R Connector
3.50.03.05P.H0R Connector
3.50.02.06P.H0R Connector
3.50.01.16P.HOR Connector
3.61.A.05P200.T28R Wiring
3.61.A.06P180.F28R Wiring
3.55.T.16P150.100R Wiring
ERP Code Part Name
Power Socket
3.30.06.AS02R
3.31.05.2122A2R Switching
3.31.03.KCD1BR Power Button
Fuse Tube
3.35.03.250B.F500MAR
3.37.GKA24.00R Transformer
8.05.01.0540R Shrinking Tube
8.05.01.2540R Shrinking Tube
5.09.01.AV12.00R Wiring
Power Cable
3.43.DA11SLMFE.01
Loader
R
3.44.01.3Y.02R Loader Frame
3.35.04.0000R Fuse Tube
3.54.20.200.YG0R Grounding
3.58.W.01P100.R20R Wiring
3.58.W.01P050.R20R Wiring
拟制： 校对：
NDX200 BOM
A1015 (Hfe 70-400) SOT-23
RN1442LA SOT-23
AIC809-31PU SOT-23 AIC
TCC8600 SQFP14X14
PCM1742 SSOP16
BA033T TO-220 ±2％
KA7805 TO-220 ±2％
SST39VF800A TSOP-48
HY57V281620 TSOP54
BU9543KV VQFP64
12MHz X2-49S
16.9344MHz X2-49S
CKX-3.5-02
AV2-8-8.4-14
2.54*4P
2.0*8P
5P*2.0
2.54*5P
6P*2.0
16P*1.0
5P*200MM 28#
6P*180MM 28#
16P*150MM 1.0
Specification
AS-02
L21-22A2
KCD1
F500mAL 250V Φ5×20
GKA24-750-A
Ф5 30mm
Ф25 40mm
1.2M
1.8M
DA11SLMFE
WSL-11VFR
FH-B02
200MM 20＃
1P*100MM 20＃
1P*50MM 20＃
审核： 日期：12/16/2009
PCS 1 A100
PCS 2 A101 A102
PCS 1 U102
PCS 1 U101
PCS 1 U108
PCS 1 U111
PCS 1 U110
PCS 1 U105
PCS 1 U104
PCS 1 U114
PCS 1 X102
PCS 1 X103
PCS 1 JK201
PCS 1 RCA100
PCS 1 J202
PCS 1 J205
PCS 1 J201
PCS 1 J103
PCS 1 J104
PCS 1 J102
PCS 1 J201
PCS 1 J104
PCS 1 J204
Unit Position
Q'ty
PCS 1
PCS 1
PCS 1
PCS 1
PCS 1
PCS 5
PCS 1
PCS 1
PCS 1
PCS 1
PCS 1
PCS 1
PCS 1
PCS 1
PCS 1
第4页，共8页
