- Page 1 MCM230 PORTABLE AIR CONDITIONER PRODUCT MANUAL SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE...
-
Page 2: Specifications
Minimum operating temperature 21°C. SPECIFICATIONS: The MCM230 is a Mono-block portable air conditioning unit. It is connected to a 13 Amp. 230Vac. 50Hz power supply and comes fitted with a fused uk moulded plug. It is recommended that the supply to the machine should be protected by a 30mA RCD... -
Page 3: Setup And Operation
PRODUCT MANUAL MCM230 PORTABLE AIR CONDITIONER SET UP AND OPERATION: • The unit is designed to operate between 21°C and 35°C. Operation outside of these temperatures could cause compressor failure and will invalidate the warranty. If the temperature in the room is above 35 C it is recommend- ed that all the doors and windows are opened and the unit run on Fan only to reduce the temperature. -
Page 4: Operation And Controls
Exhaust discharge Tank full lamp Discharge hoses Power on lamp Water drain tank Locking castors OPTIONAL THERMOSTAT: The MCM230 may come with an optional thermostat. To achieve maximum cooling capacity rotate the thermostat fully anti-clockwise. Page 4... -
Page 5: Maintenance
PRODUCT MANUAL MCM230 PORTABLE AIR CONDITIONER MAINTENANCE: Check and clean the evaporator and condenser heat exchanger coils. Build up of dust and dirt can severly effect the performance of the machine. Remove the front and rear panels and clean with compressed air. -
Page 6: Exploded View
PRODUCT MANUAL MCM230 PORTABLE AIR CONDITIONER EXPLODED VIEW: Page 6... -
Page 7: Spare Parts
PRODUCT MANUAL MCM230 PORTABLE AIR CONDITIONER SPARE PARTS: ITEM No PART No DESCRIPTION PRICE BW0201220 TOP REAR PANEL FA010124 CONDENSER FAN BW0201221 CENTRE PANEL BW0201222 REAR PANEL FR030211 CONDENSER COIL FR010122 COMPRESSOR EL020108 MAINS CABLE ME040305 TRUNK HANDLE BW0201223 RIGHT SIDE PANEL... - Page 8 PRODUCT MANUAL MCM230 PORTABLE AIR CONDITIONER Page 8...
