Romus 95120 Operating Instructions

Pico groover with guide
Hide thumbs
1
2
3

Advertisement

Table of Contents

A
Adjustment
knob
The ROMUS PICO groover, with incorporated guiding system, is used for grooving joints in
PVC and linoleum floor coverings prior to hot welding.
With this tool, you can effortlessly form a regular, uniform "U" groove along the entire length
of the joint without the need for a straight-edge.

OPERATION

Caution: keep the work area clean to avoid damage to the blade.
1. Start the groove against the skirting, with the blade facing the wall.
2. Insert the guide in the joint between the two strips and slide the PICO along the joint
while pushing it against the floor.
3. According to your preference, push or pull the grooving tool along the entire length of
the joint.
4. When you reach the opposite skirting, simply turn the groover to face the opposite
direction (with the blade facing the wall, the same position as at the start), and
complete the remaining few centimetres.
OPERATING INSTRUCTIONS
Or
PICO GROOVER WITH GUIDE
REF. 95120
B
knob
Locking
C
Blade
D
Guide
Sole plate
Réf.95120 1/3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 95120 and is the answer not in the manual?

Questions and answers

Related Manuals for Romus 95120

Summary of Contents for Romus 95120

  • Page 1 Guide Sole plate The ROMUS PICO groover, with incorporated guiding system, is used for grooving joints in PVC and linoleum floor coverings prior to hot welding. With this tool, you can effortlessly form a regular, uniform "U" groove along the entire length of the joint without the need for a straight-edge.
  • Page 2 It may, however, need adjusting for specific applications (cutting grooves in very thick or very thin floor coverings, cleaning). Guide Retaining screw 1. Loosen the retaining screw (E). 2. Alter the height of the guide (D) by pulling or pushing it into the desired position. 3. Retighten the retaining screw (E). Réf.95120 2/3...
  • Page 3 Consists in cutting a groove along a joint between two floor covering elements glued edge-to-edge (less than 1 mm) Depth of groove: for homogeneous floor coverings: 2/3 of the thickness. for non-homogeneous floor coverings: only the wear layer. Before grooving After grooving ACCESSORIES: REF. 95122 – SPARE BLADES / Pack of 10 Réf.95120 3/3...
