Operating Instructions
MOBEX F W3
(Hazardous substance-verified, welding fume separation class W3)
MOBEX F-40 W3 (Order no.: 09835)
MOBEX F-60 W3 (Order no.: 09836)
and variations
Do not use this device unless you have
read the user manual and understand it.
Translation of the original instructions
09835-08-01
