4.25 Cubic Ft. Portable Gas-Powered
Cement Mixer
Owner's Manual
Mixer
WARNING:
Read carefully and understand all ASSEMBLY AND OPERATION
INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety
precautions may result in serious personal injury.
Item #58124
READ & SAVE THESE INSTRUCTIONS
Advertisement
Table of Contents
Related Manuals for Klutch 58124
Summary of Contents for Klutch 58124
- Page 1 Cement Mixer Owner’s Manual Mixer WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #58124 READ & SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing a Klutch™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Packaging Contents ..........................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 6 Main Parts of Product ........................... 7 Assembly Instructions .......................... 8 Before Each Use ..........................11 Operating Instructions ........................ -
Page 4: Intended Use
Intended Use The Klutch 4.25 Cubic Ft. Portable Gas-Powered Cement Mixer is powered by a gas engine and features a 4.25-cubic ft. drum capacity. The drum rotates 360° for variable pouring angles. It rolls on two 10-inch solid rubber tires for easy portability. Powder-coated steel frame and drum resists corrosion. - Page 5 this equipment for a purpose for which it was not intended. • Industrial or commercial applications must follow OSHA requirements. ⚠WARNING WORK AREA SAFETY • Inspect the work area before each use. Keep work area clean, dry, free of clutter, and well-lit. Cluttered, wet, or dark work areas can result in injury.
-
Page 6: Specific Operation Warnings
and perform its intended function. Replace damaged or worn parts immediately. Never operate the product with a damaged part. • Store the product when it is not in use. Store it in a dry, secure place out of the reach of children. Inspect the tool for good working condition prior to storage and before re-use. -
Page 7: Main Parts Of Product
⚠WARNING CARBON MONOXIDE • Using an engine indoors CAN KILL YOU IN MINUTES. • Engine exhaust contains carbon monoxide. This is a poison you cannot see or smell. • NEVER use an engine inside a home or garage, EVEN IF doors and windows are open. •... -
Page 8: Assembly Instructions
Assembly Instructions ⚠WARNING • Read the ENTIRE MANUAL - IMPORTANT SAFETY INFORMATION: Read all sections of this manual including all text under subheadings therein before set-up or use of this product. 1. Place the Crossbeam (71) into the Wheel Bracket (4) so the bolt holes line up. Fasten together using Hex Bolts (64), a Flat Washer (55), and a Hex Nut (5). - Page 9 6. Use a Hex Bolt (23) to mount the Handle Plate (41) to the U-Tube (70). Fasten together with a Flat Washer (55) and a Hex Nut (5). 7. Attach the Control Handle (46) to the U-Tube (70) shaft by inserting the Coil Spring (43) into the lower hole of the Spring Base.
- Page 10 11. Mount each Mixing Blade (62) inside the assembled Drum with the pointed end facing down. The open end of each Blade should point in the direction of the Drum rotation (counter-clockwise). Fasten the Blade to the Drums using a Hex Bolt (61), Washer (55), Seal Washers (56), and a Hex Flange Nut (5).
-
Page 11: Before Each Use
Before Each Use Inspect the general condition of the mixer. Check for: loose hardware; misalignment or binding of moving parts; cracked or broken parts; damaged or cracked belts; and any other condition that may affect its safe operation. Operating Instructions ⚠WARNING •... -
Page 12: After Each Use
Before Moving or Transporting Mixer When transporting the mixer, the Lift Bar (73) must be secured with a Locking Pin (58) to hold the Lift Bar. After Each Use ⚠WARNING • Recheck all fasteners and other connections for tightness. 1. Once materials are mixed, tilt the Drum and dump the mixture where needed. The Drum will rotate while the mixture is dumping. - Page 13 Maintain the mixer by adopting a program of conscientious repair and maintenance in accordance with the following recommended procedures. It is recommended that the general condition of any tool be examined before it is used. Keep your tool in good repair. Keep handles dry, clean, and free from oil and grease.
-
Page 14: Troubleshooting
Troubleshooting ⚠WARNING • Follow all safety precautions whenever diagnosing or servicing the tool. Disconnect power supply before service. Use the table below to troubleshoot problems before contacting service personnel or your local dealer. If the problem continues after troubleshooting, call your local dealer for assistance. Failure Possible Cause Corrective Action... -
Page 15: Parts Diagram
Parts Diagram Parts List Part Number Part Description Quantity Cotter Pin 5x40 Flat Washer 27 Wheel Wheel Bracket Hex Nut M8 Engine Bracket Plate Clip Bolt M4x8 Nut M4 Shield Engine Box Shield Bolt M4x8 Page 15 of 19... - Page 16 Part Number Part Description Quantity Engine Engine Pulley Bolt M5x12 Belt Drum Pulley Hook Engine Hood Hex Bolt M8x40 Hex Bolt M8x25 Hook Clamp Hex Bolt M8x65 Bearing 6002Z Ring Shield Attached Aluminum Bracket Ring Shield Pinion Shaft Gear Spacer Flat Key Spring Washer M6 Flat Washer M6...
-
Page 17: Replacement Parts
Part Number Part Description Quantity Spring Washer M14 Washer U-Tube Crossbeam Support Bracket Lift Bar Hex Flange Nut M6 Elastic Washer Replacement Parts • For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. • Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. -
Page 18: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or "Us'') warrants to the original purchaser only ("You'' or "Your") that the Klutch product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 19 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 19 of 19...
