Summary of Contents for TLC asta
- Page 1 ASSEMBLY INSTRUCTION asta MODULAR STAIRS...
- Page 2 Stairs are not adapted for use in rooms where the presence of big groups of children without NUMBER OF STEPS supervision is expected and in buildings intended for people with disabilities. Modular stairs ASTA should be used in accordance with their intended use as the element of a building or the shape 340-380 530-522...
-
Page 3: Necessary Tools
FASTENERS Below we present a set of tools necessary to assembly modular stairs ASTA. While using any of these tools you should We present you below the fasteners of ASTA stairs together with the amount of pieces depending on the number be careful, and while performing assembly works, you should comply with health and safety regulations. - Page 4 MAIN ELEMENTS OF THE SYSTEM MAIN ELEMENTS OF THE SYSTEM We present you below the modular elements of ASTA stairs together with the amount of pieces depending on the Left foot Right foot Left start module Right start module number of stairs. They are marked with numbers 1 - 15, which will help you to identify those elements in assembly drawings.
- Page 5 - mechanic and chemical. You can obtain assistance concerning the selection of anchors in a technical specialty store. Stairs manufacturer ASTA recommends using anchors M12 of anchorage depth of 130mm. Anchors should be bedded in accordance with manufacturer’s instructions. In the case where stairs are assembled to steel elements, you should use screws M12 in class 8.8 and spring washer.
- Page 6 While installation and assembling the railings, make sure that they are placed in one line. Railings are carrying element of the ASTA stairs and their proper installation has a considerable impact on the rigidity of the structure. asta...
- Page 7 In the case where there is 10 or more steps, it is necessary to install bracings in the form of cables 14 and 15. At the It’s high time to admire your new stairs and yourself as well. In the end, the self-assembly of ASTA stairs allowed you previous stage, you screwed lower grips for the cables to the feet of the stairs.
-
Page 8: Technical Information
(survey) made within an ad hoc inspection of the structure performed to see In modular stairs ASTA it is possible to adjust step height, in accordance with the regulations and depending on the type if there are any damages directly threatening the safety of users. - Page 9 Produced by: CERTIFIED MANUFACTURER TLC Sp. z o.o. ul. Chopina 25N 38-300 Gorlice, POLAND asta tlc.eu MODULAR STAIRS info: +48 505 140 140...
