TF-GFRC-FBWGR-30
TF-GFRC-FBWSN-30
TF-GFRC-FBWBR-30
Installation and Operating Instructions
All Fire Bowls have ventilation designed into each bowl.
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS APPLIANCE
These fire pit burners are manufactured from the factory for Natural gas only. If you intend using LP gas then
you must purchase a LP conversion kit. See Table of Contents for LP converstion kit information.
Warning: For Outdoor Use Only
MODELS
Natural Gas
Adobe Fire & Water Bowl
PN#90416
DO NOT DISCARD. THIS MANUAL
HAS IMPORTANT OPERATING AND
MAINTENANCE INSTRUCTIONS.
LEAVE WITH THE HOMEOWNER.
MODEL:
SERIAL #:
Description
29½" x 12 ½" Grey Concrete Bowl
29½" x 12 ½" Sand Concrete Bowl
29½" x 12 ½" Brown Concrete Bowl
Advertisement
Table of Contents
Related Manuals for AMD DIrect TF-GFRC-FBWGR-30
Summary of Contents for AMD DIrect TF-GFRC-FBWGR-30
- Page 1 LEAVE WITH THE HOMEOWNER. MODEL: SERIAL #: MODELS Natural Gas Description TF-GFRC-FBWGR-30 29½” x 12 ½” Grey Concrete Bowl TF-GFRC-FBWSN-30 29½” x 12 ½” Sand Concrete Bowl TF-GFRC-FBWBR-30 29½” x 12 ½” Brown Concrete Bowl Adobe Fire & Water Bowl Installation and Operating Instructions All Fire Bowls have ventilation designed into each bowl.
- Page 2 Fuels used in gas fired appliances, and the products of combustion such as fuels, contain chemicals known to cause cancer, birth defects and/or other reproductive harm. This warning is issued pursuant to the California Health & Safety Code Sec. 25249.1 AMD Direct Fire and Water Bowl REV. A...
-
Page 3: Table Of Contents
This drying out period should be no less than 30 minutes. Continue monitoring the flame from distance to ensure that all popping has ceased before fully enjoying the fire. AMD Direct Fire and Water Bowl REV. A... -
Page 4: Specifications
11.0” WC (2.73kPa) Table 3 Gas Pressures WARNING: Proper clearances from combustible materials must be maintained from all sides, top and bottom of this bowl. Use the specifications listed for proper clearance to combustibles. AMD Direct Fire and Water Bowl REV. A... -
Page 5: Preparing A Location For Your Fire Bowl
PREPARING A LOCATION FOR FIRE FEATURE NOTE: The AMD Direct Fire bowls are constructed of Glass Fiber Reinforced Concrete (GFRC). The bowl weighs 83 LBS without media or the burner system installed. Ensure the structure you are placing these fire features on is solid enough to securely hold the weight. -
Page 6: Gas Pipe Sizing Chart
This chart is for reference only, we recommend you consult with a Licensed Plumber/Gas Fitter or NFPA54 (National Fuel Gas Code - current edition) for more details. Table 4 Gas Pipe Sizing Chart AMD Direct Fire and Water Bowl REV. A... -
Page 7: Pre Installation Checklist
Natural Gas (NG) orifice. LP gas needs more ventilation and requires the removal of the stainless sleeve on the venturi tube to provide a cleaner flame. See Fig. 4 and page 14 for more detail. AMD Direct Fire and Water Bowl REV. A... -
Page 8: Installation Requirements Of Fire Bowl
Lower the burner pan assembly back into the bowl, resting on the inside lip and conduct a test fire. After test fire is complete, proceed to placing media on top of burner. Fig. 5 Installing burner assembly into the bowl. AMD Direct Fire and Water Bowl REV. A... -
Page 9: Fire & Water Bowl Requirements
Once the water line is secured, turn ON the water and check for any leaks, then finish the gas line as instructed on page 8. Fig. 8 Shows flex connector (not supplied) water line. AMD Direct Fire and Water Bowl REV. A... -
Page 10: Installation Of Lava Rock/Media
MEDIA PREPARATION MEDIA SPECIFICATIONS The AMD Direct Fire Bowl models are approved for use with lava rock. Use the media supplied in the bottom of the bowl. 30” bowls use 22 lbs of AMD Direct, lava rock Lava rock height should be level and no higher than the top lip of the bowl (approximately 2“... -
Page 11: Fire Bowl Operation
1. Insert key into shut-off valve and secure into square end. See Fig. 10. 2. Turn key clockwise until it stops. 3. After cooling off install cover. Fig. 11 Inserting Key into Valve Fig. 12 Lighting fire pit with lighter AMD Direct Fire and Water Bowl REV. A... -
Page 12: Replacement Parts
⅜” Flex Non-Whistling Gas Line 16” Long T100-9898-16 Natural Gas Orifice #18 (4.3mm) LOF-BO-NG18 5A Liquid Propane Gas Orifice #36 (2.7mm) LOF-BO-LP36 Key Valve BVL2S 12” Chrome Plated Key KEY-PC-12 Chrome Flange (decorative flange used with BVSL2S) CVR-BVL2CP AMD Direct Fire and Water Bowl REV. A... -
Page 13: Maintenance
Please also note that fissures (hairline cracks), can appear on the surface due to age and/or exposure to the atmospheric conditions. These commonly don’t have an effect on durability and do not compromise the structural integrity of the product. AMD Direct Fire and Water Bowl REV. A... -
Page 14: Lp Conversion
ON the gas supply and conduct a leak test before presuming normal use. Fig. 13 Shows main burner orifice. Note: No Teflon tape or thread compound is required when threading brass to brass fittings. AMD Direct Fire and Water Bowl REV. A... -
Page 15: Troubleshooting
2. Ensure a non-whistling flex connector is being used. No Water at Scupper 1. Ensure the water shut OFF is fully open. 2. Check for any blockage at the outlet of the scupper. AMD Direct Fire and Water Bowl REV. A... -
Page 16: Optional Accessories
OPTIONAL ACCESSORIES The following accessories are available from your local AMD Direct dealer/distributor. Each accessory comes with a separate installation manual. Read each instruction thoroughly before installing. LP Gas Regulator Media LP Tank Enclosure Gas regulator for LP gas installations. -
Page 17: Warranty
AMD DIRECT LIMITED WARRANTY - 2022 / 2023 AMD DIRECT hereby warrants to the end user that products will be free from material and workmanship de- fects that prevent safe and correct operation of the product. The warranty commences from date of sale to the end user for the following period: CONSUMER RESIDENTIAL APPLICATIONS –... - Page 18 ACCESSORIES • LIFETIME WARRANTY - CONSTRUCTION AND MANUFACTURER DEFECTS • LIFETIME WARRANTY - STAINLESS STEEL COMPONENTS (LIDS, STAINLESS STEEL COVERS) • ONE (1) YEAR WARRANTY – ESTOP1-OH, ESTOP2-5H WINDSHIELDS, HOSES AND REGULATORS AMD Direct Fire and Water Bowl REV. A...
- Page 19 The manufacturer may request defective products returned with an RMA (Return Merchandise Authorization) issued by AMD DIRECT for specific products, which is considered to be the nature of the defect and or warranty claim. Product to be returned should; be packed so as not to incur damages during transportation. AMD DIRECT is not responsible for damages on returned items.
- Page 20 We do not authorize any person or company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return, or replacement of its equipment, and or such representation are binding. AMD DIRECT 17322 Gothard St. Huntington Beach, CA 92647 www.amddirect.com Phone: 800-966-8126 AMD Direct Fire and Water Bowl REV. A...
- Page 21 What are the symptoms? Please be prepared to explain. Be prepared to send photos to us when on the phone. 10. Found missing or damaged parts? Let us know ASAP or send photos. Fire Pits AMD Direct Fire and Water Bowl FPSS 3-30-16 REV. A...
