ORSTEEL Light ALPHA ZENITH Technical Manual

TECHNICAL SHEMATICS
INSTALLATION SCHEMATICS
1
75
Drill a hole with a hole saw.
3
Not submerged
All data are given for information purposes only. They do not constitute a contractual commitment on our part and are subject
to change at any time.
61 61
2
Connector IP44
4
Serial wiring 350-700mA
TECHNICAL MANUAL
ALPHA ZENITH
350mA-700mA
IP44
A A+ A++
The powerful ceiling recessed Alpha Zenith swivel spotlight can be flush
mounted in a straight or sloping suspended ceiling. This spotlight is used for
accent lighting in any room and provides excellent interior architectural lighting.
The aesthetic "Trimless" surround and its low luminance make it very popular
with designers. The added extra of Alpha Zenith: A perfect finish to the ceiling
after fitting, with no need to retouch the plasterwork.
Air gap Electrical features
POWER
Insulator
SUPPLY
POWER
SUPPLY
5 at
WIRING
20mm
Characteristics
lighting techniques
AVERAGE LIFE OF THE
LED
COLOUR EMISSION
BEAM
INITIAL OUTFLOW
0,2
T° max 55°C
IK03
75 mm
Mechanical characteristics
1x9W SIZE
350mA-700mA WEIGHT
Not included MATERIAL
Serial
General characteristics
OPERATING
TEMPERATURE
INGRESS PROTECTION IP44
IMPACT RESISTANCE
60 000 hours
Certified L90 B10
ENERGY CLASS
2700°K - 3000°K
APPLICANCE CLASS
4000°K - 6000°K
13° / 24° / 44° / 115°
WALKOVER FIXTURE
558lm at 3000k
DRIVE-OVER FIXTURE
WIRES
PHOTOBIOLOGICAL
SAFETY
Ø80x61mm
0,2 kg
Solid aluminium
- 20°c ~+ 60°
IK03
A / A+ / A++
CLASS III
NO
NO
Supply wire 2x0,34
mm2 in IP68
Risk group I
