ORSTEEL Light ALICIA Technical Manual

TECHNICAL SHEMATICS
90
PM PMMA MA D DIFFU IFFUSANT
INSTALLATION SHEMATICS
1
Wire ref CAB0010
max 10mm
Flexible ref TA802
Mortar
Tile
Concrete
Water level
Sealing casing
Fourreau
Sealing casing
to the edge of
the mortar
Connect to the ground
Sealing Casing
56 56
16 160 0
24,5
80 80
Parallel wiring 24VDC
All data are given for information purposes only. They do not constitute a contractual commitment on our part and are subject
to change at any time.
61 61
SANT
2
max 10mm
Tighten the
cable gland
Concrete
Water level
3
Concrete
Water level
TECHNICAL MANUAL
2, 2,5 5
ALICIA
24VDC
A A+ A++
IP69
The Alicia recessed submersible spotlight lights and enhances ponds, swimming pools.
It is also totally watertight for use in a marine environment. Its high luminous flux gives
an opal diffusion with a pinpoint light effect. It is guaranteed watertight, duplex 316L
stainless steel to IP69 standard.
Electrical features
3x2.5W
POWER
SUPPLY 24VDC
POWER SUPPLY Not included
WIRING Parallel
Features
lighting technology
AVERAGE LIFE OF THE 60 000 hours
LED Certified L90 B10
COLOR EMISSION 2700K - 3000K -
4000K - 6000K
RED - GREEN
BLUE - AMBRE
10°-25°-40°-115°
ANGLE BEAM
INITIAL OUTFLOW 634lm at 3000k
0,15
ACS
T° max 55°C
IK10
Mechanical features
DIMENSIONS
WEIGHT
MATERIAL
General features
OPERATING
TEMPERATURE
INGRESS PROTECTION IP69
IMPACT RESISTANCE
ENERGY CLASS
APPLICANCE CLASS
WALKOVER FIXTURE
DRIVE-OVER FIXTURE
WIRES
PHOTOBIOLOGICAL
SAFETY
Ø90mmx61
0,15kg
Inox 316L
electropolished
- 20°c ~+ 60°
IK10
A / A+ / A++
CLASS III
NO
NO
2x0,5mm² in IP68
Risk group I
