INSTRUCTION MANUAL
20V Cordless Brushless Brad Nailer and Stapler
Model # PS76170A
Have product questions or need technical support? Please scan the QR code to enter our official
website and contact us!
Website:
www.powersmartusa.com
Toll free: 1-800-791-9458 M-F 9-5 EST
Email: support@amerisuninc.com
Website
Advertisement
Table of Contents
Related Manuals for Powersmart PS76170A
Summary of Contents for Powersmart PS76170A
- Page 1 INSTRUCTION MANUAL 20V Cordless Brushless Brad Nailer and Stapler Model # PS76170A Have product questions or need technical support? Please scan the QR code to enter our official website and contact us! Website: www.powersmartusa.com Toll free: 1-800-791-9458 M-F 9-5 EST Website Email: support@amerisuninc.com...
-
Page 3: Table Of Contents
Maintenance……………………………………………………...………. 17 Trouble shooting…………………………………………………………. 18 Exploded view & parts list………………………………………………… 19 Warranty statement………………………………………………………. 22 TECHNICAL DATA 20V Cordless Brushless Brad Nailer and Stapler Model # PS76170A Nail gauge: Nail type: Brad nail / 1/4"Narrow crown s taple Brad nail length: 5/8"~2"... -
Page 4: Introduction
INTRODUCTION ® Thank You for Purchasing a PowerSmart Product. This manual provides information regarding the safe operation and maintenance of this product. Every effort has been made to ensure the accuracy of the ® information in this manual. PowerSmart reserves the right to change this product and specifications at any time without prior notice. -
Page 5: General Safety Rules
GENERAL SAFETY RULES Safety is a combination of common sense, staying alert, and knowing how your power tool works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: Do not operate this unit until you read this instruction manual for safety, operation and maintenance instructions. Failure to follow all instructions listed below may result in electric shock, fire, and/or serious personal injury. - Page 6 CAUTION: In all cases, make certain the outlet in question is properly grounded. If you are not sure if it is, have a licensed electrician check the outlet. WARNING: Do not expose to rain or use in damp locations. Guidelines for using extension cords Make sure your extension cord is in good condition.
- Page 7 Use safety equipment. A Dust mask, non-skid safety shoes, hard hat, or hearing protection must be used for appropriate conditions. Wear a full face shield if you are producing metal filings or wood chips. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts.
- Page 8 If you lend this tool to someone else, also lend them these instructions. BATTERY TOOL USE AND CARE WARNING: USE ONLY POWERSMART APPROVED REPLACEMENT BATTERIES, OTHER BATTERIES MAY CAUSE INJURY OR DAMAGE TO THE NAILER. Use with POWERSMART 20V battery.
- Page 9 Proper care for battery Off-season storage To obtain the longest possible battery life, we suggest the following: Remove the battery pack from the charger once it is fully charged and ready for use. For battery pack storage longer than 30 days: Store the battery pack where the temperature is below 80°F and away from moisture.
-
Page 10: Special Safety Rules For Brad Nailer
SPECIFIC SAFETY RULES FOR BRAD NAILER Always assume that the tool contains fasteners. Careless handling of the nailer can result in unexpected firing of fasteners and personal injury. Do not point the tool towards yourself or anyone nearby. Unexpected triggering will discharge a ... -
Page 11: Symbols
LOADING TOOL Do not load the tool with fasteners when any one of the operating controls is activated. Never place a hand or any part of body in fastener discharge area of tool. Never point tool at anyone. ... -
Page 12: Knowing Your Brad Nailer
KNOWING YOUR BRAD NAILER LED worklight grip switch Trigger switch LED worklight Depth of drive adjustment wheel No-mar pad Contact trip Low nail indicator window Magazine Indicator light Mode selector Belt hook Battery Magazine latch Extra NO-mar pad Fig.1 Unpacking Unpack the power tool and all its parts, and compare against the list below. -
Page 13: Assembly Instruction
WARNING:Never load nails with the contact trip or trigger activated. Personal injury may result. WARNING:Always remove battery pack before loading or unloading nails. Serious personal injury may result. When replacing nails in your model PS76170A, follow these guidelines: Nail Type: Brad nail: Ga18 (1.25×1.0mm) Nail length: 15-50mm (5/8 "... - Page 14 1. Press magazine latch (M) and open sliding magazine (H) . 2. Insert a stick of fasteners into the magazine channel. ●For brad nails, the pointed ends of the fasteners are resting on the bottom edge of the magazine when loading. Latch ●For staples, the head of the staples are resting on the top of the magazine.
-
Page 15: Operating Instruction
To remove the battery pack Press the battery release button ,Slide the battery pack backward, and then pull or lift the battery out of the tool . WARNING: Follow these instructions in order to avoid injury and to reduce the risk of electric shock or fire: •... - Page 16 Single sequential actuation mode Single sequential actuation provides the most accurate nail placement. 1. Remove battery pack from the tool . 2. Slide the selector up to the single sequential actuation mode(See fig.4). 3. Reinstall the battery, reactivate tool. 4. Place the contact trip against the workpiece and pull the trigger to drive a nail.
-
Page 17: Maintenance
CLEARING JAMMED NAILS/STAPLES WARNING: Remove the battery pack before removing nails or clearing a jammed nail. Failure to do so could result in serious personal injury. A jammed nail must be cleared before using the nailer again. This Nailer is designed with the unjammed nails device, you can only open the magazine and then the jammed nails/staples will be dropped out. -
Page 18: Trouble Shooting
TROUBLE SHOOTING The following form lists the common operating system with problem and solutions. Please read the form carefully and follow it. WARNING: If any of the following symptoms appears during your operating, stop using the tool immediately, or serious personal injury could result. Only a qualified persons or an authorized service center can perform repairs or replacement of tool. -
Page 19: Exploded View & Parts List
EXPLODED VIEW & PARTS LIST... - Page 20 Item Stock# Description Qty. Item Stock# Description Qty. PS76170A-001 Bolt M4X8 PS76170A-035 O-ring 42.5X2.5 PS76170A-002 Washer PS76170A-036 Cylinder Seat PS76170A-003 Short Rod PS76170A-037 O-ring 56X2.4 PS76170A-004 PS76170A-038 Big Cylinder PS76170A-005 Bolt PS76170A-039 Big Piston Ring PS76170A-006 Spring PS76170A-040 Big Piston...
- Page 21 Item Stock# Description Qty. Item Stock# Description Qty. PS76170A-069 Motor Gear PS76170A-103 Safty Guard PS76170A-070 Motor PS76170A-104 Safty Cover PS76170A-071 Light Pipe PS76170A-105 Pressure Plate PS76170A-072 Nailer Body 1 PS76170A-106 Bolt ST2.9X6.5 PS76170A-073 Display Light Pipe PS76170A-107 Bolt M5X20 PS76170A-074...
-
Page 22: Warranty Statement
Limited Warranty, you must return the entire power tool product; transportation prepaid, to PowerSmart Include a legible copy of the original receipt, which lists the date of purchase (month and year) and the name of the company purchased from.
