QUICK INSTALLATION GUIDE
MODEL: RESERVE-BAT-1-DC-10.1-INT

1.0 Transport

NOTICE
▪ Risk of injury when li�ing the ba�ery as the ba�ery weighs 90 kg. There is risk of injury if the ba�ery
is li�ed incorrectly while being transported.
▪ Transport the ba�ery always as described below.
▪ Handle with care, choose the corresponding handling method according to the weight, and pay
a�en�on to safety.
During transporta�on, please follow these guidelines:
1. The original packaging should be used for transporta�on.
2. Handle with care, choose the corresponding handling method according to the weight, and pay a�en�on to
safety.
3. During transporta�on, please keep the packaging away from dangerous sources and take waterproofing
measures.
4. Secure the packaging during transporta�on.

2.2. Dimensions

≥
NOTICE
For addi�onal ba�eries, keep a minimum spacing of 300mm. Do not stack ba�eries.
≥300mm ≥300mm ≥300mm
⑥
548267 Rev. A
Safety and Installa�on Instruc�ons
for SunPower Reserve
≥ ≥
≥300mm ≥300mm
①
②

2.0 Product Overview

(1)
(2)
(1) Power bu�on
(2) Ba�ery circuit breaker
(3) LED display
(4) BAT+ power connector
(5) BAT- power connector
(6) Grounding
(7) BMS COM 1
(8) BMS COM 2 (with terminal resistor)

2.1. LED Display

The three LED indicators on the front cover provide informa�on about the State of Change (SOC) opera�onal status
of the ba�ery.
Symbol
LED Indicator
LEDs show the
SOC status
01

2.3. Scope of Delivery

(X1) (X1)
(X12)
(X4)
1x BAT- 1x
BAT+

2.4. Mounting Location

IP65 90 kg
03
(3)
(4)
(5)
(6)
(7) (8)
(6)
(*)
Descrip�on
White LEDs flash
White LEDs on
LEDs are off
No. SOC
1
2
10%＜SOC≤30%
3 30%＜SOC≤50%
4 50%＜SOC≤60%
5 60%＜SOC≤90%
6 90%＜SOC≤100%
(X1) (X2)
(X1)
(X4)
(X1)
(X1)
0°
50℃
-10℃
Descrip�on
SOC≤10%
02
(X3)
(X2) (X1)
04
