- Page 1 SHALLOW ACTIVE SUBWOOFER MANUAL SWS10/SWS12 SWS10/SWS12 RECOIL 10" /12" Shallow Active Subwoofer User Manual...
- Page 2 SHALLOW ACTIVE SUBWOOFER MANUAL SWS10/SWS12 Thank you for your purchase and welcome to RCEOIL ! In order to enjoy the better service from us, please keep your original invoice well and complete the warranty card. You'd better post the copy of the warranty card back to the appointed service agent of RCEOIL, So that you may get more technical support.
- Page 3 SHALLOW ACTIVE SUBWOOFER MANUAL SWS10/SWS12 WARNING Do not disassemble or alter. Doing so may result in an accident, fire or electric shock. Use this product for mobile 12V applications. Use the correct ampere rating when replacing fuses. Failure to do so may result in fire or electric shock.
- Page 4 SHALLOW ACTIVE SUBWOOFER MANUAL SWS10/SWS12 CAUTION Halt use immediately if a problem appears. Failure to do so may cause personal injury or damage to the product. Return it to your authorized dealer or the nearest Service Center for repairing, Have the wiring and installation done by experts.The wiring and installation of this unit requires special technical skill and experience.
- Page 5 MOUNTING 1.Attach the inclucled mounting plates with the supplied screws. 2.Once the mounting plates are attached, position the SWS10/SWS12 in the desired location within the vehicie. Before securing, check to make sure all the screw locations can affix to a structurally solid surface, while avoiding vehicle...
-
Page 6: Wiring Diagram
SHALLOW ACTIVE SUBWOOFER MANUAL SWS10/SWS12 WIRING DIAGRAM Power connector +12V Power Boost (0db-9db) +12V Remote (-)12V Ground Phase (0 -180 Low Pass Filter 30Hz-150Hz FUSE (20A) LEVEL RCA Input (Low level) Remote Level Controller Jack Speaker Input connector (High Level) - Page 7 Connect to Left and Right Speaker (+/-) high level inputs. 6. Phase Select Switch With this switch at 0 , the SWS10/SWS12 output will be in phase with full-range speakers in the system. At 180 , it will be out of phase. It may be advantageous to try both positions, depending on the particular vehicle or subwoofer location.
- Page 8 SHALLOW ACTIVE SUBWOOFER MANUAL SWS10/SWS12 WIRING DIAGRAM Power Connector Boost 0db-9db Bass Remote Level Control Phase Select Switch 0 -180 Low Pass Filter 30Hz -150Hz FUSE(20A) +12V BATT LED indicator RCA Input(Low level) Blue: Power ON Red: Protection/Fault Speaker Input connector( High Level )
