- Page 1 UNDERSEAT ACTIVE SLIM SUBWOOFER SL1779 SL1779 Underseat Active Slim 7" X 9" Subwoofer with Passive Radiators User Manual...
- Page 2 Please read this OWNER'S MANUAL thoroughly to familiarize yourself with each control and function. We hope that your new underseat active subwoofer SL1779 will give you many years of listening enjoyment. In case of problems when installing your subwoofer, please contact support@recoilaudio.com.
- Page 3 UNDERSEAT ACTIVE SLIM SUBWOOFER SL1779 • BEFORE WIRING, DISCONNECT THE CABLE FROM THE NEGATIVE BATTERY TERMI- NAL. Failure to do so may result in electric shock or injury due to electrical shorts. • DO NOT ALLOW CABLES TO BECOME ENTANGLED IN SURROUNDING OBJECTS.
-
Page 4: Service Care
UNDERSEAT ACTIVE SLIM SUBWOOFER SL1779 • DO NOT INSTALL IN LOCATIONS WITH HIGH MOISTURE OR DUST. Avoid installing the unit in locations with high incidence of moisture or dust. Moisture or dust that penetrates into this unit may result in product failure. - Page 5 1. Attach the included mounting brackets to the SL1779 with the supplied screws. (See to Fig. 1) 2. Once the brackets are mounted to the SL1779. Place the subwoofer in the desired location within the vehicle. Before securing with screws, check to make sure all screws can affix to a structurally solid surface while avoiding vehicle wiring, components, etc.
-
Page 6: Connections (Fig.3)
UNDERSEAT ACTIVE SLIM SUBWOOFER SL1779 Mounting Bracket Bracket Screws, Remote Bass Level Knob CONNECTIONS (Fig.3) Before making connections, be sure to turn the power off to all audio compo- nents. Connect the red battery lead from the amp directly to the positive (+) terminal of the vehicle's battery. - Page 7 UNDERSEAT ACTIVE SLIM SUBWOOFER SL1779 Fig.3 RCA Input System Head Unit, etc (sold separately) RCA Extension Cable (sold separately Note: Power Mode button must be set to REM (Button Out) Front Left Speaker (White+) Front Left Speaker (White/Black-) Ground Lead (Black)
- Page 8 UNDERSEAT ACTIVE SLIM SUBWOOFER SL1779 3. Fuse (30A) USE ONLY THE CORRECT AMPERE RATING WHEN REPLACING FUSES. Failure to do so may result in fire or electric shock. 4. Input/Power Wire Harness 5. Speaker Input Leads These leads are input leads for use with head units not equipped with preamp outputs.
- Page 9 UNDERSEAT ACTIVE SLIM SUBWOOFER SL1779 Fig.3 Speaker level input system Left Speaker Right Speaker Note: Connect to each speaker lead (splice) without Note: Connect toeach speaker breaking the lead (splice) without breaking the connection between connection between the the headunit and headunit andthe speaker.
- Page 10 (set to +") before making the input gain adjustment. Set the SL1779 input gain to the minimum position. Using a dynamic CD as a source, increase the head unit volume until the output distorts. Then, reduce the volume 1 step (or until the output is no longer distorted).
- Page 11 UNDERSEAT ACTIVE SLIM SUBWOOFER SL1779 SL1779 connection panel CONNECTION CHECKLIST (Fig. 5) Please check your head unit for the conditions listed below: (Fig, 4) a. The head unit does not have a remote turn-on or power antenna lead. b. The head unit's power antenna lead is activated only when the radio is on (turns off in the tape or CD Mode).
- Page 12 UNDERSEAT ACTIVE SLIM SUBWOOFER SL1779 ① Blue/White ② Power Antenna ③ Remote Turn-On Lead ④ To other components' Remote Turn-On L eads ⑤ SPST Switch (optional) ⑥ Fuse (3A) ⑦ As close as possible to the vehicle's ignition tap ⑧ lgnition Source...
