WARNING!
Read this Operator's Man-
ual carefully before using
this tool. Failure to under-
stand and follow the con-
tents of this manual may
result in electrical shock,
fire, and/or serious per-
sonal injury.
Operator's Manual
For support and additional information
about using your microDRAIN APX go
to
support.seesnake.com/microdrain
or scan this QR code.

Advertisement

Table of Contents
loading

Related Manuals for RIDGID SeeSnake microDRAIN APX

Summary of Contents for RIDGID SeeSnake microDRAIN APX

  • Page 1 Operator’s Manual WARNING! Read this Operator’s Man- ual carefully before using this tool. Failure to under- For support and additional information stand and follow the con- tents of this manual may about using your microDRAIN APX go result in electrical shock, support.seesnake.com/microdrain fire, and/or serious per- or scan this QR code.

  • Page 2: Table Of Contents

    Table of Contents Introduction Regulatory Statements ..................... 3 Safety Symbols ......................3 General Safety Rules Work Area Safety ...................... 4 Electrical Safety ......................4 Personal Safety ......................4 Equipment Use and Care ..................5 Pre-Operation Inspection ..................6 See Snake microDRAIN APX Overview Description .......................

  • Page 3: Regulatory Statements

    NOTICE indicates informa- NOTICE UK Importer tion that relates to the pro- Ridge Tool UK (RIDGID) tection of property. 44 Baker Street This symbol means read the man- London W1U 7AL, UK ual carefully before using the equipment.

  • Page 4: General Safety Rules

    Touching equip- drain inspection equipment at the ment or plugs with wet hands can in- same time, wear RIDGID drain clean- crease the risk of electrical shock. ing gloves. Never grasp the rotating 4 – English – microDRAIN APX...

  • Page 5: Equipment Use And Care

    • Use only accessories that are rec- cause hand injuries. Only wear latex or ommended by the manufacturer for rubber gloves underneath RIDGID drain your equipment. Accessories that may cleaner gloves. Do not use damaged be suitable for one piece of equipment drain cleaning gloves.

  • Page 6: Pre-Operation Inspection

    Pre-Operation Inspection 8. Observe the work area and erect bar- riers as necessary to keep bystanders away. WARNING See additional product specific safety information and warnings on page 10. To reduce the risk of serious injury from electrical shock or other causes, and to prevent damage to your equipment, in- spect all equipment and correct any problems before each use.

  • Page 7: See Snake Microdrain Apx Overview

    SeeSnake TruSense Enabled Monitor, The microDRAIN APX can also be used the microDRAIN APX flips your on-screen with the RIDGID micro CA-350 handheld image as the camera rotates through the inspection monitor using the CA-350 pipe, ensuring your image remains oriented adapter accessory and docking handle, upright.

  • Page 8: Specifications

    Specifications Specifications Mimimum bend Weight 5.25 kg [11.6 lbs] 19.1 mm [0.75 in] radius Dimensions 32 mm to 76 mm Pipe Capacity § [1.25 in to 3 in] Width 337 mm [13.3 in] System Cable 3 m [10 ft] Depth 224 mm [8.8 in] Length Operating Environment...

  • Page 9: Components

    Components Carry Handle SeeSnake System Cable Case Latch Push Cable Guide Camera Clip SeeSnake Color ID TrueSense Counter System Cable Wrap Kickstand Slip-Ring Serial Number Module microDRAIN APX – English – 9...

  • Page 10: Specific Safety Information

    This section contains important safety drains. Drains may contain chemicals, information that is specific to the RIDGID bacteria and other substances that See Snake microDRAIN. Read these pre- may be toxic, infectious, cause burns cautions carefully before using the or other issues.

  • Page 11: Operating Instructions

    Operating Instructions Opening the microDRAIN APX Case Placement WARNING Set up your microDRAIN APX near the pipe Make sure the camera is completely in- entrance so you can manipulate the push side the drum before unlatching and cable while viewing the display. Use the opening the microDRAIN APX case.

  • Page 12: Installing The Drum

    Installing the Drum Inspection Overview The microDRAIN APX case gives you the To perform a pipe inspection, connect any ability to swap out the drum when the job See Snake monitor to the reel, power on the requires a different push cable and camera system, push the push cable through the combination.

  • Page 13: Pipe Guides

    Removing the Slip Ring Connecting to the CSx Via Assembly The CSx Via Wi-Fi inspection device can be connected to the microDRAIN APX through 1. Disconnect the system cable from the the slip-ring cavity. Remove the slip-ring as- reporting monitor and remove the mon- sembly from the microDRAIN APX and in- itor from the docking system.

  • Page 14: Maintenance And Support

    Cleaning Service and repair of the camera reel must be performed at a RIDGID Independent Clean your system with rags and a soft Authorized Service Center. To find your nylon brush. If desired, a mild detergent or nearest service center or for any service or disinfectant can be used.
  • Page 15 microDRAIN APX – English – 15...
  • Page 16 RIDGID and the RIDGID logo are trademarks of Ridge Tool Company, registered in the USA and other countries. All other registered and unregistered trademarks and logos mentioned herein are the property of their respective owners.
