Summary of Contents for DigitalZone UDG-4004NS
-
Page 2: Table Of Contents
Contents Ultra High Definition Generator(UDG) ················································································ 3 Product Overview ·························································································································· 3 Package and accessories ············································································································ 4 Remote control unit ····················································································································· 5 Operation ·········································································································································· 6 Play List menu ································································································································· 7 Playing file ········································································································································· 8 How to change Left/Right in 3D ··························································································· 9 Changing playing order in a list ····························································································... -
Page 3: Ultra High Definition Generator(Udg)
One 3840x2160 UD content file is divided and cropped into 4 Full HD content files and uploaded to UDG-4004NS. Built-in 4 decoder of UDG-4004NS playback 4 Full HD content file and delivers to 4K converter board, which output to UD resolution. -
Page 4: Package And Accessories
(Grade A), which acquired EMC (Electronic magnetic Capability), and it is intended to be used in areas, except for a domestic purpose. ※ Digitalzone will not be responsible for any problems caused by using any other adopter we don't provide. -
Page 5: Remote Control Unit
Remote control unit... -
Page 6: Operation
Operation Connect adapter to the product. Connect HDMI cable to product and TV. Turn on power switch located at front of the product. Auto play will proceed. ※ Booting time is about 1 minute. -
Page 7: Play List Menu
Play List menu Play List menu – Remote Control Unit00 Press LIST on remote control to open Play List menu. -
Page 8: Playing File
Playing file Play List can be controlled to loop play with checked file(s). Checked file(s) will be activated and loop play while unchecked file(s) are deactivated. Move Play Play desired file by Move to desired file with pressing ENTER on remote UP/DOWN key on front control or PLAY icon on touch control or remote... -
Page 9: How To Change Left/Right In 3D
How to change Left/Right in 3D If 3D content’s Left and Right is changed, press “EXT. ” key on remote to change Left/Right. Left/Right change How to change Left/Right in 3D Changing playing order in a list Move up Selected file will move up. Move down Selected file will move down. -
Page 10: Setting Multiple Play List
Setting multiple Play List Different Play List can be made among 10 lists. 1. In order to configure Play List, playing status must be stopped. 2. Press Left/Right key of remote in order to move from Play List. - Page 11 Example) When you want to create Play List into “Play List 3” 1. Open ‘Play List’ menu after stop “cursor shows move to “PlayList3”. the file play. Using “◀▶” ※Available only with remote controller direction key, move to “Play List 3”. List shows available stream files.
-
Page 12: Deleting File(S) From Play List
Deleting file(s) from Play List File(s) deleted from PLAY LIST will be moved to SYSTEM menu, submenu of Update for backup. Backup file(s) can be updated again Move Move to desired file which should be deleted from Play List with direction keys. -
Page 13: Resolution
Resolution Only when playing status is stopped, resolution can be modified. Press ‘RESOLUTION’ button on remote control. Move to desired resolution. Press ‘ENTER’ to change resolution. -
Page 14: Update Menu
UPDATE menu Update menu – Remote Control Unit Press UPDATE on remote control to open Update menu. Use Left/Right button “◀ ▶” to move from media source. ※ USB media menu will only appear when USB storage is connected. -
Page 15: Updating File(S) In System (Hdd)
Updating file(s) in SYSTEM (HDD) Backup file(s) in SYSTEM can be updated to Play List UPDATE menu Press ‘UPDATE’ button on remote control Select media to SYSTEM Using direction key “◀▶” select media to SYSTEM. Choosing a file to update Use ‘Check’... -
Page 16: Updating File(S) With Usb Storage Device
Updating file(s) with USB Storage Device ※ USB media menu will only appear when USB storage is connected. Select Multi-Play List Press ‘List’ button to check Play List information. Move cursor, using direction button to designated Play List number and press ‘UPDATE’ button to update menu. 1. - Page 17 ※ Do not power off during update. Updated file(s) is/are damaged when power is manually turned off during updating stage. Delete all file(s) updated to Play List when manually turned off and repeat update procedure once again.. 5. Check update Press LIST button to open LIST menu to check update process.
-
Page 18: Deleting File(S) From System
Deleting file(s) from System ※ File deleted from the ’Play List’ can be permanently deleted from system in ‘update’ menu - Delete only from the list: When file is deleted from list, deleted file is still stored in SYSTEM. - To permanently delete from the product: File must be deleted from list and SYSTEM. Select File from PlayList Press ‘LIST’... -
Page 19: Set Up Menu
SET UP menu 00SETUP menu – Remote Control Unit ⊙ Press SETUP on remote control to open SETUP menu. System Firmware Date & Time... -
Page 20: System
SYSTEM Set Refresh Rate.(※HDMI Cable(s) must be connected during setting) Press ‘SETUP’ button to open Set up menu. Use LEFT/RIGHT direction keys to move to desired features. (※ Status is pre-set to ‘SYSTEM’.) Use UP/DOWN direction keys to move to sub menu. Press ‘ENTER’... -
Page 21: Firmware
Firmware (※ Version and model can differ from image.) Press ‘SETUP’ button to open Set up menu. Use LEFT/RIGHT direction keys to move to FIRMWARE. Press ‘ENTER’ button to set sub menu selection. When firmware upgrade is finished, press “Power” button on remote to operate. “NEW VERSION”... -
Page 22: How To Schedule Date & Time
How to schedule Date & Time ※ Item selection : direction keys on remote control. ※ Selection & setting : ‘ENTER’ button on remote control. 1. Select item by using direction keys and make the item ‘ENABLE’ status. 2. “Power On Time” : Scheduling power ON time of UDG. 3. -
Page 23: Troubleshooting
Troubleshooting Error Troubleshooting A : Check power LED on front panel. If it is not Q : No power. on, please check power cable connection A : 1)Check power of TV. 2) See if LED is on. If it is on, check HDMI cable Q : No display on TV connection. -
Page 24: Specification
Output : DC 12V 16A Size / Weight 43.5x29x10(WxDxH, CM) / 7.0KGS * Specification and design, subject to change without notice to enhance performance. DigitalZone Co., Ltd (Guro-dong, E&C VENTURE DREAM TOWER2,), -1001, 55, Digital-ro33-gil, Guro- gu, Seoul, KOREA, TEL : 02-6330-2360...
