Sealey MAJ20 Instructions

Thank you for purchasing a Sealey Jack. Manufactured to a high standard this product will, if used according to these instructions
and properly maintained, give you years of trouble free performance.
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND CAUTIONS.
USE THIS JACK CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE
DAMAGE OR PERSONAL INJURY, AND WILL INVALIDATE THE WARRANTY. RETAIN THESE INSTRUCTIONS FOR FUTURE USE.
1. SAFETY INSTRUCTIONS
3 Disconnect jack from air supply before changing parts, servicing or performing any maintenance.
p WARNING! ensure correct air pressure is maintained and not exceeded. Recommended pressure
3 Keep air hose away from heat, oil and sharp edges. Check air hose for wear before each use, and ensure that all connections are secure.
3 Ensure Jack is kept clean and in good working order. Immediately repair or replace damaged parts.
3 Use recommended parts only. Incorrect parts may be dangerous and will invalidate the warranty.
3 Use a qualified person to lubricate and maintain the Jack. DO NOT use brake fluid to top up system. Use Sealey hydraulic oil only.
3 Locate Jack in an adequate, well lit working area for its function, and keep area clean and tidy and free from unrelated materials.
3 Use Jack on level & solid ground, preferably concrete. Avoid tarmacadam since Jack may sink in.
3 Place wedges under wheels of vehicle (but ensure wheels of Jack can freely move).
3 Ensure the vehicle handbrake is engaged (or in “PARKED” mode), and switch the engine off.
3 Ensure minimum distance of 0.5m between vehicle tilt & static objects such as doors, walls, etc.
3 Ensure all non essential persons keep a safe distance and that there are no passengers in the vehicle to be jacked up.
3 Place Jack under vehicle manufacturer’s recommended jacking points (see vehicle hand book).
3 Check that the jacking point is stable and centred on the Jack saddle and is free from grease or oil.
3 Ensure Jack wheels are free to move and there are no obstructions.
s DANGER: Use Jack for lifting only, NOT for supporting the jacked load. Use correct axle stands under vehicle before proceeding with task.
7 DO NOT apply your body weight to the handle during jacking. The handle is only for moving the jack to and from the jacking location.
7 DO NOT operate the Jack if parts are missing or damaged.
7 DO NOT exceed the rated capacity of the Jack.
7 DO NOT allow the vehicle to move during jacking and do not use the jack to move the vehicle.
7 DO NOT Jack a vehicle which may result in the spillage of fuel, battery acid, or dangerous substances.
7 DO NOT work under the vehicle until Axle Stands have been correctly positioned.
7 DO NOT use the Jack for purposes other than which it is designed.
7 DO NOT adjust the safety overload valve.
7 DO NOT yank the hose from the air supply, and DO NOT direct air from the air hose at yourself or others..
3 Ensure there are no persons or obstruction beneath the vehicle before lowering.
3 When not in use disconnect jack from the air supply, and store in the down position in a safe, dry, childproof area.
p WARNING! turn off air supply and de-pressurise the control nozzle before removing the pump unit from any installation or mobile system.
Failure to comply with this instruction may damage the unit and will invalidate your warranty.
2. SPECIFICATIONS
Model: . . . . . . . . . . . . . . . . . . . . . . . . .MAJ20 . . . . . . . . . . . . . . . .MAJ10-20 . . . . . . . . . . . . . . . . . .MAJ20-60
Max capacity . . . . . . . . . . . . . . . . . . . .20Tons . . . . . . . . . . . . . . . . . .20Tons . . . . . . . . . . . . . . . . . . . .60Tons
Min height . . . . . . . . . . . . . . . . . . . . . .205mm . . . . . . . . . . . . . . . . . .180mm . . . . . . . . . . . . . . . . . . . .175mm
Max height capacity:
Stage 1 (mm/tons) . . . . . . . . . . . . . . . . .320/20 . . . . . . . . . . . . . . . . . . .270/20 . . . . . . . . . . . . . . . . . . . .255/60
Stage 2 (mm/tons) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .370/10 . . . . . . . . . . . . . . . . . . . .330/40
Stage 3 (mm/tons) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .480/20
Piston stroke . . . . . . . . . . . . . . . . . . . .115mm . . . . . . . . . . . . . . . . . .115mm . . . . . . . . . . . . . . . . . . . .233mm
Length inc handle . . . . . . . . . . . . . . . .1832mm . . . . . . . . . . . . . . . . .1764mm . . . . . . . . . . . . . . . . . . .2231mm
Width . . . . . . . . . . . . . . . . . . . . . . . . . .300mm . . . . . . . . . . . . . . . . . .300mm . . . . . . . . . . . . . . . . . . . .315mm
Working PSI . . . . . . . . . . . . . . . . . . . .100-145 . . . . . . . . . . . . . . . . . .100-145 . . . . . . . . . . . . . . . . . . .100-145
Weight kg . . . . . . . . . . . . . . . . . . . . . . . . . .44 . . . . . . . . . . . . . . . . . . . . . .40 . . . . . . . . . . . . . . . . . . . . . . . .76
Required air flow . . . . . . . . . . . . . . . . . .14cfm . . . . . . . . . . . . . . . . . . .14cfm . . . . . . . . . . . . . . . . . . . . .14cfm
Note: The maximum heights shown may be extended by use of the extension pin (fig 4).
3. AIR SUPPLY
3.1. Ensure the jack pneumatic switch is in the "off" position before connecting to the air supply.
3.2. You will require an air pressure of more than 100PSI (max 145PSI) and an air flow of 14cfm to get the best performance from this jack.
3.3. p WARNING! Ensure the air supply does not exceed 145psi while operating the jack. Too high an air pressure and unclean
air will shorten the products life due to excessive wear, and may be dangerous causing possible damage and personal injury.
3.4. Keep the air hose between the compressor and the air jack as short as possible, and install an air filter and oiler (fig 1).
3.5. Drain the air tank daily. Water in the air line will damage the jack.
3.6. Clean the air inlet filter screen weekly.
3.7. Line pressure should be increased to compensate for unusually long air hoses (over 8 metres). The minimum hose diameter should
be 3/8" I.D. and fittings must have the same inside dimensions.
INSTRUCTIONS FOR
AIR / HYDRAULIC JACKS
MAJ20, MAJ10-20, MAJ20-60.
Model No’s:
100-145PSI required air flow
MAJ20, MAJ10-20, MAJ20-60 - 0025 - 160698
270 l./min.
