Summary of Contents for Sawo A Generic

  • Page 1 A Generic Sauna Room Assembly Manual Classic Bench Piano Bench Wave Bench Version: 1.5 Note: Above images are for illustrative reference only and may differ from actual item.
  • Page 2: Table Of Contents

    TABLE OF CONTENT Parts List Exterior and Interior ............3 Parts List Interior (L-type Bench) .............4 Parts List Interior (Wave-type Bench) ..........5 Screws for Room Exterior and Interior ..........6 Wall Assembly ................7 Ceiling Assembly ................9 Moulding Installation Sequence ............. 10 Interior Furnishes Assembly ............12 Interior Furnishes Assembly (Bench Support) .........
  • Page 3: Parts List Exterior And Interior

    Parts List Exterior Ceiling Assembly Wall Elements Exterior Mouldings Top Exterior Mouldings Bottom Exterior Mouldings Main Base Frame ABS Bolt Leveler Door Set Parts List Interior Back Rest Top Bench Cover Top Bench Frame Bench Siding Lower Bench Cover Lower Bench Frame Bench Supports Flooring Collapsible heater guard...
  • Page 4: Parts List Interior (L-Type Bench)

    Parts List Interior (L-type Bench) *For larger sauna room. Upper Bench Cover 1A Upper Bench Cover 1B Upper Bench Frame 1A Upper Bench Frame 1B Diagonal Support Bench Siding Upper Bench Support Diagonal Support (L-type Lower Bench) Lower Bench Cover 2A Lower Bench Cover 2B Lower Bench Support Frame 2A Lower Bench Support Frame 2B...
  • Page 5: Parts List Interior (Wave-Type Bench)

    Parts List Interior (Wave-type Bench) *For room with wave design benches. Upper Bench Cover Upper Bench Frame Upper Bench Support Lower Bench Cover Lower Bench Frame Lower Bench Support Bench Siding Collapsible heater guard Parts List Interior (L-type Wave Bench) *For room with larger wave design benches.
  • Page 6: Screws For Room Exterior And Interior

    Screws for Room Exterior 6RM08-123 / 6RM08-123 / 6RM08-109 / 6RM08-109 / 6RM08-951 6RM08-951 Vertical Moulding Small Vertical Moulding 22mm thick 42mm thick ABS Bolt Leveler Twist to adjust height 6RM08-027 / 6RM08-919 Door Jamb 6RM08-123 / Screw Cap Door Jamb 6RM08-109 / 6RM08-951 Horizontal Moulding...
  • Page 7: Wall Assembly

    Wall Assembly Connect base frames according to their corresponding numbers. No. 1 is underneath the door and numbers increase clockwise. Use Leveler to make the frame leveled. Twist ABS BOLT to adjust height. For big sauna room base frame connection. Optional.
  • Page 8 Wall Assembly Attach wall panels according to their label. Take note of the grooves direction (arrow direction). Wall 4 Wall5 Wall 2 Wall 3 Tongue and Groove Wall3 Wall6 Wall 1 Wall2 Wall7 Wall1 Plan View Secure walls with cam locks. Isometric View Allen Wrench Before moving on to securing the next wall element, make sure that both cam locks...
  • Page 9: Ceiling Assembly

    Ceiling Assembly Attach ceiling assembly via tongue to *Ceiling assembly for big sauna room Groove. (more than 1 ceiling) Ceiling to ceiling connection side view Interior ceiling moulding Check that the 6RM08-123 / ventilation hole 6RM08-109 / is in the right position (refer 6RM08-951 to plan drawing...
  • Page 10: Moulding Installation Sequence

    Moulding Installation Sequence From the inside, follow the sequence below. Internal top mouldings 6RM08-123 / 6RM08-109 / 6RM08-951 Internal Top Moulding Internal corner mouldings 6RM08-123 / 6RM08-109 / 6RM08-951 Corner Moulding Internal wall mouldings 6RM08-123 / 6RM08-109 / 6RM08-951 Vertical Moulding 42mm thick Internal horizontal bottom mouldings...
  • Page 11 From the outside, follow the illustration sequence below. Horizontal Moulding 6RM08-123 / 6RM08-109 / 6RM08-951 Horizontal Moulding 75mm thick Vertical Moulding 6RM08-123 / 6RM08-109 / 6RM08-951 Vertical Moulding 42mm thick Vertical Moulding Small 6RM08-123 / 6RM08-109 / 6RM08-951 Vertical Moulding Small 22mm thick Horizontal Moulding 6RM08-123 /...
  • Page 12: Interior Furnishes Assembly

    Interior Furnishes Assembly Attach bench support at suggested height with screws, then place over the bench frame assembly and screw to wall. Bench Support • If using wall mounted heater, make sure to install the mounting plates before installing the heater guard. •...
  • Page 13 Attach top/lower bench covers and flooring. On large sauna rooms, the flooring needs to be placed first as it will be hard to place inside once the bench supports are installed. Classic Bench Piano Bench Wave Bench Note: Above images are for illustrative reference only and may differ from actual item.
  • Page 14: Interior Furnishes Assembly (Bench Support)

    Interior Furnishes Assembly (Bench Support) *For big sauna rooms Attach bench support at suggested height. Diagonal Support for upper bench support 6RM08-125 / 6RM08-923 Diagonal Support Diagonal supports should be installed so that they are flushed with the bench frame. T-Support For Lower Bench Support.
  • Page 15: Interior Furnishes (Bench Covers)

    Interior Furnishes (Bench Covers) *For big sauna rooms Attach upper and lower bench covers, then proceed with the heater guard. Lastly attached the flooring. Upper Bench Lower Bench Collapsible heater guard Flooring 6RM08-032 / 6RM08-921 Heater Guard Classic Bench Piano Bench Wave Bench 6RM08-032 / 6RM08-921...
  • Page 16: Electrical Layout

    Electrical Layout Electrical/Wiring locations. Electrical Conduit Locations: For heater and regulating sensor. For sauna light switch and heater control. Conduit For sauna light. Sauna Light Ventilation Wire Installation: Install junction / utility box /power controller into the ceiling roof as indicated. Insert wires into the electrical conduit designated for thesauna light switch (for NB heaters) or sauna control Junction Box...
  • Page 17 Sensor Installation Note: Sensor installation is for Separate control heater models only. A pre-drilled hole for the sensor is provided for separate control heaters. Sensor is placed directly above the heater. Refer to the heater control instruction manual for the sensor installation.
  • Page 18: Sauna Maintenance

    If there is calcium stains or other dirt on the heater cover, clean it with mild soap water. You can also use SAWO Decalcifying solution for washing the stains. Dry after wash. Clean glass surfaces with window cleaning agent or dish soap. Rinse well and dry with a squeegee or a dry cloth.
  • Page 19 Subject to change without notice. www.sawo.com | info@sawo.com...
