IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step
instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of 2 persons is required to assemble this product.
• All assembly fittings should always be tightened properly. Screws should not be loose because a clild can squeeze
PRODUCT INFORMATION
• Made from Pine with NC lacquer finish.
• Made in China.
• Natural features ensure that each piece is individual. Every effort is made to ensure colour continuity between
pieces, however this is a natural product, slight colour variations and natural grain markings may occur.
CARE INSTRUCTIONS
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Always use a non-silicone based furniture polish. Silicone in furniture polishes can break down the lacquer finish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent
scratching or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
793094 SALISBURY SINK CONSOLE
ASSEMBLY INSTRUCTIONS.
Page 1 of 7
Advertisement
Table of Contents
Related Manuals for Next SALISBURY 793094
Summary of Contents for Next SALISBURY 793094
- Page 1 793094 SALISBURY SINK CONSOLE ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
- Page 2 FITTINGS B × 16 C × 16 A × 16 J × 2 PARTS Page 2 of 7...
- Page 3 STEP ONE 1. Attach 1 x magnet (G) to panel(4) by 2 x screws(H), tighten with a screwdriver. 2. Insert 4 x dowel (C ) to panel (8) &(9) 3. Attach 2 x metal plate (J) to 2 x door panel(5) by 2 x screws(I),tighten with a screwdriver.
- Page 4 STEP TWO 1. Attach panel (6) to panel (8) by 3 x screws(D), tighten with a screwdriver. STEP THREE 1. Attach assembled panel (6), (8) & panel (9) to panel (2). 2. Insert 5 x camlocks(B) into panel (6),(8) & (9), tighten with a screwdriver.
- Page 5 STEP FIVE 1. Attach panel (4) to panel (2) and Insert 1 x camlock(B) to panel 4, tighten with a screwdriver. 2. Attach panel (3) onto assembled unit and insert 8 x camlocks(B), tighten with a screwdriver. Ensure the arrow indicators on the camlocks are pointing towards the panel edges and ensure the assembly bolts locate properly into the camlocks before turning clockwise with a screwdriver to...
- Page 6 STEP SEVEN 1. Lie down assembled unit. 2. Insert 2x screws (D) to panel (4), tighten with a screwdriver. STEP EIGHT 1. Attach 1 x wall attachment strap (R) to the back of the top panel with 1 x washer (Q) and 1 x screw (S). Page 6 of 7...
- Page 7 STEP NINE 1. Attach 2 x door panel (5) hinge arm (L) to hinge component (K) on side panels. 2. Attach 2 x handles (O) to door panels (5) by 2 x screws (P), tighten with a screwdriver. 3. To align doors use the adjustment diagram below STEP TEN 1.
