794415 ASHTON SIDE TABLE
ASSEMBLY INSTRUCTIONS.
IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.
Tools Needed
Helpline
If you have any problems with this product or require
any replacement fittings please contact Customer
Services Tel: 0844 844 8999
Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found
to be faulty. Should you need to return the unassembled product, please repack in the original packaging.
IMPORTANT
• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step instructions.
• Carefully check that you have all parts before beginning assembly.
• Keep fittings out of children's reach and keep children well away from the construction area.
• We recommend that the packaging is used to protect the surfaces during assembly.
• A minimum of two persons is required to assemble this product.
• We recommend the use of the wall attachment bracket/strap provided for safety reasons.
PRODUCT INFORMATION
• Made from MDF material.
• Made in China.
CARE INSTRUCTIONS
• Gloss finishes are prone to light surface scratching and it is therefore very important that you care for
this item correctly.
• For general cleaning, periodically dust with a soft cloth.
• Do not rub or scrub the surface when cleaning.
• Do not use furniture polish.
• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.
• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent scratching
or damage.
• Do not put hot dishes directly on the surfaces of the item.
• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or
warping.
• Never drag pieces of furniture across the floor as this will cause damage to the joints.
• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.
Page 1 of 6
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Next ASHTON 794415
Summary of Contents for Next ASHTON 794415
- Page 1 794415 ASHTON SIDE TABLE ASSEMBLY INSTRUCTIONS. IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY. Tools Needed Helpline If you have any problems with this product or require any replacement fittings please contact Customer Services Tel: 0844 844 8999 Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found to be faulty.
- Page 2 FITTINGS PARTS Page 2 of 6...
- Page 3 STEP ONE 1. Insert 4 x dowels C into top panel (1), insert 4 x cambolts A into top panel (1) with a screwdriver, and attach drawer stop O to top panel (1) using 1 x screw J with a screwdriver. 2.
- Page 4 STEP TWO 1. Attach 2 x handles D to drawer front (8) using 4 x screws E with a screwdriver. 2. Insert 4 x cambolts A into drawer front (8) with a screwdriver. 3. Attach drawer side panel (9) & (10) to drawer front (8) using 4 x cam-locks B with a screwdriver.
- Page 5 STEP FOUR 1. Attach top panel (1) to the unit using 4 x cam-locks B. Ensure the arrow indicators are pointing to the panel edges and ensure the cambolts locate properly into the cam-locks before tightening with a screwdriver. STEP FIVE 1.
- Page 6 NOTE: Wall fixings are not included, source suitable fixings for your wall type. If in doubt consult a qualified tradesperson. Next Retail Ltd, Desford Road, Leicester, LE19 4AT Page 6 of 6...
