Area Intrusion
Area Intrusion detects people, vehicles, or objects that enter and loiter in a pre-defined
virtual region.
Steps:
1. Go to Seven Grid Menu → Smart Event → Perimeter Protection → Area Intrusion.
2. Select a camera.
3. Turn on Enable.
4. Set detection rules and detection areas.
1) Select the Number to set Arming Area. Up to 4 arming areas are selectable.
– Click Clear or set four points in the preview window to clear or draw a quadrilateral
detection region.
2) Set Sensitivity. The size of the object that can trigger the alarm. The higher the value is, the
easier the detection alarm can be triggered. Its range is [1-100].
5. Set the arming Schedule. Refer to for Configure Arming Schedule below for details.
6. Set the Trigger process. Refer to Configure Alarm Trigger process below for details.
7. Optional: Click Advanced setting to Set Target Detection as Human Shape Filter or Vehicle
Shape Filter to discard alarms which are not triggered by human body or vehicle.
8. Click Apply.
● Click clear all to delete all alarm areas, you can also click clear to delete individual areas.
Figure 6-3-3-3 Intrusion Detection
