AVARRO NX-TXL3790 Quick Start Manual

Tilt x-large tv mount 37-90"/175lb
Hide thumbs Also See for NX-TXL3790:

Advertisement

Quick Links

V3
NX-TXL3790
Tilt X-Large TV Mount 37-90"/175lb
P 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the NX-TXL3790 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AVARRO NX-TXL3790

  • Page 1 NX-TXL3790 Tilt X-Large TV Mount 37-90"/175lb...
  • Page 2 ENGLISH 1. Limited Warranty a. General Subject to the terms and conditions of this Limited Warranty, from the date of sale through the period of time for product categories specified in Section 1(a), ADI warrants ADI branded products to be free from defects in materials and workman- ship under normal use and service, normal wear and tear excepted.
  • Page 3 a. Specific Warranties for product categories are as follows : B Connectors Limited Lifetime Bus Terminals Limited Lifetime Extension Cords Limited Lifetime HDMI Cables Limited Lifetime Jacks, Cords and Intrusion Communication Accessories Limited Lifetime Patch Cables Limited Lifetime Patch Panels & Brackets Limited Lifetime Raceway Conduit Limited Lifetime...
  • Page 4: Tools Needed

    4. Returns Subject to the terms and conditions listed below, during the applicable warranty period, ADI will replace Product or provide a credit at purchase at its sole option free of charge any defective products returned prepaid. Any obligations of ADI to replace Limited Lifetime warranty products pursuant to this warranty which result from defect are limited to the availability of replacement product.
  • Page 5 HARDWARE PRODUCT NUMBERS M4 x 30 M6 x 30 M8 x 30 M4 x 12 M6 x 15 M8 x 15 M8 x 50 LAG BOLT WALL SQUARE LAG BOLT 10mm STEEL 8mm x 65mm ANCHOR WASHER SPACER STEEL WASHER SPACER WASHER PRODUCT COMPONENT PARTS...
  • Page 6 STEP 1A - CONNECT VERTICAL RAILS TO TV Connect Vertical Rails to TV Conecte el adaptador al monitor Connectez l'adaptateur au moniteur STEP 1B - IF MORE CLEARANCE IS NEEDED Connect Vertical Rails to TV Conecte el adaptador al monitor Connectez l'adaptateur au moniteur Spacers can be used when more clearance is required.
  • Page 7 STEP 1- USE M8 STEEL WASHER IF THE PHILLIPS SCREWS FROM THE MONITOR KIT ARE TOO LONG Diagrams show three possible options for using additional washers if hardware screws are too long to properly tighten into the back of the TV. OPTION OPTION OPTION...
  • Page 8 STEP 2- WOOD STUD INSTALLATION (CONCRETE INSTALLATION SKIP TO STEP 3) Find stud and mark edge and center locations Ubique el panel y marque las ubicaciones de los bordes y el centro Repérez l'emplacement d'une poutre, puis marquez l'emplacement des bords et du centre de cette poutre ”) 60mm STEP 2A &...
  • Page 9 STEP 2C- MOUNT WALL PLATE TO WALL Mount wall plate Coloque la placa de pared Montez la plaque murale...
  • Page 10 STEP 3 – SOLID CONCRETE INSTALLATION Use wall plate to mark mounting locations/ drill pilot holes Use la placa de pared para marcar el lugar donde se realizará la instalación Utilisez la plaque murale pour marquer l'emplacement de montage Level Solid Concrete Drill Bit Drill Pilot Hole...
  • Page 11 STEP 3C- SOLID CONCRETE INSTALLATION Mount wall plate Coloque la placa de pared Montez la plaque murale Concrete Wall Hammer Concrete Wall Insert wall anchors gently into concrete wall with hammer if necessary STEP 4A- ATTACH TV TO WALL PLATE & ADJUST TILT ANGLE Hang vertical rails with TV attached Tilt Cuelgue con el monitor adherido...
  • Page 12 STEP 4A- ATTACH TV TO WALL PLATE & ADJUST TILT ANGLE Tilt -3°~12° Rotate lever clockwise to hold desired tilt 1/2”...
  • Page 13 STEP 4B- ADJUST THE SCREWS ON THE VERTICAILS TO LEVEL THE TV Maximum leveling adjustment 0.5”...
  • Page 14 STEP 4C- ADDITIONAL SECURITY FEATURE (OPTIONAL) Vertical Rails Wall Plate Vertical rails have 7mm hole located at the bottom for placement of pad lock for additional theft) security (pad lock not included)
  • Page 15 STEP 4D - ADJUST STRAP LENGTH (OPTIONAL) Attach pendant to wall plate with magnet. Squeeze and hold control to adjust cord length...
  • Page 16 NX-TXL3790 CAUTION: DO NOT EXCEED MAXI - MUM WEIGHT CAPACITY. SERIOUS INJURY OR PROPERTY DAMAGE MAY OCCUR! Max Loading Weight: 175 lbs 40049 30312 PN: NX-TXL3790...
