Summary of Contents for MIRKA ROS
- Page 2 Parts Page TO VACUUM SYSTEM FOR CENTRAL VAC INLET INLET TORQUE SETTING NOTE ITEM in.-lbs. (Nm) 55 - 65 (6.2 - 7.3) 16 - 20 (1.8 - 2.3) 60 - 72 (6.8 - 8.1) 36 - 48 (4.0 - 5.4) 30 - 35 (3.4 - 3.9)
-
Page 3: Parts List
Parts List Item Description Qty. MPA0040 RETAINING RING MPA0021 BEARING MPB0017 REAR ENDPLATE MPA0005 CYLINDER ASSEMBLY MPA0042 O-RING MPB0005 ROTOR MPA0010 VANE MPA0041 KEY MPB0016 FRONT ENDPLATE MPA0019 BEARING MPA0045 O-RING MPA0001 LOCK RING MPB0277 5 mm (3/16 in.) ORBIT AirSHIELD™ SHAFT BALANCER FOR 125 mm (5 in.) PADS MPB0278 5 mm (3/16 in.) ORBIT AirSHIELD™... - Page 4 MPA0798 Air Inlet Kit MPA0980 Shaft Balancer Kit Muffler Kit Code: 8993018811 150mm/5,0 Kit Code: 8993017311 Code: 8993010611 MPA0802 ROS MPA1670 Shaft Balancer Kit Spindle Bearing Kit 150mm/2,5 Kit Code: 8993019711 Code: 8993013711 MPA0988 CV Swivel MPA0994 Cylinder & O-ring Kit MPA0993 Lock Ring &...
- Page 5 • Read all instructions before using this tool. All operators must be fully trained in usage and safety of this tool. • All maintenance must be carried out by trained personnel. For service, contact Mirka authorized service centre! • Always wear required safety equipment (see warnings).
-
Page 6: Work Stations
Please Read and Comply with Putting the Tool into Service Use a clean lubricated air supply that will give a measured air 1) General Industry Safety & Health Regulations, Part 1910, pressure at the tool of 6.2 bar (90 psig) bar when the tool is run- OSHA 2206, available from: Superintendent of Documents;... -
Page 7: Technical Data
Mirka, Ltd. cannot be held responsible for the consequences of using declared values instead of actual exposure values for any individual risk assessment. -
Page 8: Troubleshooting Guiide
Ring groove. Remove Motor Assembly and rein- stall the Motor Assembly. See ”Motor Disassembly“ and ”Motor Assembly“. Motor parts worn. Overhaul Motor. Contact authorized Mirka Service Center. Worn or broken Spindle Bearings Replace the worn or broken Bearings. See ”Shaft Balancer and Spindle Disassembly“...
