Ugur UDD 45 DTK Operating Manual

Commercial type vertical frozen food storage cabinet
Hide thumbs Also See for UDD 45 DTK:

Advertisement

Table of Contents

COMMERCIAL TYPE VERTICAL FROZEN FOOD
STORAGE CABINET
EN
OPERATING MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UDD 45 DTK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ugur UDD 45 DTK

Summary of Contents for Ugur UDD 45 DTK

  • Page 1 COMMERCIAL TYPE VERTICAL FROZEN FOOD STORAGE CABINET OPERATING MANUAL...
  • Page 2 | User Manual...
  • Page 3 RXX at the end of the model name on the rating label of model. The RXX mean which refrigeration gas used and the energy class of the device. THIS MANUAL COVERS THE FOLLOWING MODELS UDD 45 DTK UDD 440 DTKL NF UDD 45 DTKL UDD 440 DTKLE NF...
  • Page 4 INFORMATION Dear Customer, In order to use more efficiently your product, which was manufactured and quality controlled in Uour company plants with great care, we kindly request you to read this manual carefully and completely before starting using your product, to keep it for further reference and to use your product according to the terms stated herein.
  • Page 5 Dear Customer, Points to consider within this manual are indicated under the headings WARNING, CAUTION, NOTEE and SUGGESTION These headings are defined according to the degree of importance and we kindly request you to read each of them carefully. The information stated under headings WARNING, CAUTION, NOTEE and SUGGESTION in this operating manual applies for all stages during the period of use of your product, including transportation and installation.
  • Page 6 TABLE OF CONTENTS A - Things that must be done before using your product and security warnings. B - General appearance and technical specifications of your product C - Installation of your product. D - Using your product E - Cleaning, maintenance and transportation of your product F - Things that must be done before calling Authorized Service | User Manual...
  • Page 7 A- THINGS THAT MUST BE DONE BEFORE USING YOUR PRODUCT AND SECURITY WARNINGS WARNING! • Do not place your product to a place exposed to direct sunlight or influence area of the heat sources such as stove, radiator core, oven, cooker, radiant and infrared. Otherwise, this may cause performance decrease, damage of your product or make it become dysfunctional (Picture 1).
  • Page 8 A- THINGS THAT MUST BE DONE BEFORE USING YOUR PRODUCT AND SECURITY WARNINGS WARNING! • When you place packages, which are not packed, properly packed and cause leakages to your device, liquid leaks from the foodstuff may cause corrosion on the metal parts of your storage cabinet, gas leakage at the pipes, yellowing on the plastic parts, cracks and disappearance of thee hygiene conditions, odour formation and reproduction of the microorganisms that may pose a threat for your health.
  • Page 9 A- THINGS THAT MUST BE DONE BEFORE USING YOUR PRODUCT AND SECURITY WARNINGS NOTE It is at the discretion of the consumer entirely to take action related to the food inside your product in case of any failure. Our company is not responsible from the deterioration of your foodstuff due to any failure or usage error.
  • Page 10 A- SECURITY WARNINGS WARNING! • The products mentioned in this manual are designed and manufactured under control according to national and international security norms. • Following rules must be followed for a safe and secure use. • Check that your outlet is suitable for the operation of your product. Always use your product with grounded socket.
  • Page 11 A- SECURITY WARNINGS CAUTION! Please check the refrigerant gas written on your product label. Following 5 clauses cover the products containing R600a and R290 Hydrocarbon gas. • Installation of this device must be only made by Authorized Service for reducing flammability dangers.
  • Page 12 B- GENERAL APPEARANCE OF YOUR PRODUCT Canopy Control Panel Shelves Shelf Height Adjustment Line Lighting Glass Door Door Handle Lower grill | User Manual...

  • Page 13: Selecting The Place Of Installation

    C- INSTALLATION OF YOUR PRODUCT Selecting the place of installation The operating environment of the product is very important for the smooth operation of your product. While selecting the operating environment, Do not place your product exposed to outdoor environment (on the street, avenue, etc.). Be careful for not obstructing lower shutter of the product with materials such as cardboard, box etc.
  • Page 14 C- INSTALLATION OF YOUR PRODUCT PICTURE 4 PICTURE 5 In commercial products: Climate Class Temperature Range Humidity Class 3 25 °C 60% Rh Class 4 30 °C 55% Rh Class 5 40 °C 40% Rh Climate Class of your product is indicated on the technical specification label on the product. Positioning Possible placement positions: 1- In a way that the back side alone is opposite to the wall;...

  • Page 15: Installation

    C- INSTALLATION OF YOUR PRODUCT Installation Before positioning, remove and disassemble all packaging materials and bottom wooden pallet of the product. (It may be necessary to lift your device for removing the bottom pallet). Insert the replacement parts inside your product according to the installation instructions. Only use genuine spare parts.

  • Page 16: Electric Connection Rules

    C- INSTALLATION OF YOUR PRODUCT Electric Connection Rules The product will start when you insert the plug into the outlet as shown in picture 8. WARNING! It is forbidden to insert the plug into multiple socket and to use extension cord (Picture 9). There is no separate on-off switch on your product.
  • Page 17 D- USING YOUR PRODUCT Start-up WARNING! • This operating manual applies for various device models. Hardware scopes of the models may vary. There may be differences in the pictures. • Clean inside and all accessories of your product before the first start up. •...
  • Page 18 D- USING YOUR PRODUCT Setting Internal Temperature of Your Device Temperature setting of your product has made at the factory in a manner that it is operated under the most appropriate conditions. Be careful for always placing frozen product inside your product. Preservation temperature of the products can be observed from the digital indicator or thermostat under its canopy and adjusted by means of an electronic thermostat.
  • Page 19 D- USING YOUR PRODUCT Using Digital Thermostat Thermostat Adjustments (ERC 112D) Set Temperature The explanations regarding the symbols on the thermostat and general information about the settings are given be low. 1) [ ] : Defrost Key 2) [ ] : Stand by Key 3) [ ] : Up Key 4) [...
  • Page 20 D- USING YOUR PRODUCT General Informatıon and Instructıons Keys; Press and release, increases the sliding options among menu options and enables transition. 2- [ ]/Light: Internal menu status, reduces sliding values among menu options or enables transition. When you press for 5 seconds, the Light turns on/off. 3- [ ]/(Esc): Press and release, return to the previous menu and approval of parameter values.
  • Page 21 D- USING YOUR PRODUCT Thermostat Adjustments (CRA) Keys; The explanations regarding the sybols on the thermostat and general informtion about the settings are given below. 1) [ ] - Displays the control setpoint. Exit the control setpoint and save the changes. 2) [ ] - Cancel and return to standard mode.
  • Page 22 D- USING YOUR PRODUCT Set Temperature To set the operating temperature of your device, press the [ ] key. The Setpoint value Use the [ ] keys to set the desired value. Press the [ appears on the display. to confirm the modification. Manual Defrost ] key for 5 seconds on the thermostat.

  • Page 23: Loading Foodstuff To Your Product

    Do not load your product with food over the loading line. MODEL MAX. SHELF MODEL MAX. SHELF CARRYING CARRYING CAPACITY CAPACITY UDD 45 DTK 10 kg. UDD 440 DTKL 25 kg. UDD 45 DTKL 10 kg. UDD 440 DTKLB 25 kg. UDD 65 DTKL 15 kg.

  • Page 24: Shutting Down Your Product

    D- USING YOUR PRODUCT Shutting down your product Transfer the foodstuff inside your product to a convenient place. Unplug your product (Picture 14). If your product will not be used for a long time, apply following considerations; Clean your product. Otherwise the humidity on the wall may cause darkening of the internal surface. PICTURE 14 CAUTION! If your product will be stored at an indoor place after shutdown;...

  • Page 25: Internal Cleaning

    E- CLEANING, MAINTENANCE AND TRANSPORTATION OF YOUR PRODUCT CLEANING Cleaning of your device is composed of two stages, which are the internal cleaning and external cleaning. Following warnings must certainly be abided before start cleaning. CAUTION! Unplug your product before every cleaning. Always wear protective gloves during cleaning and maintenance.

  • Page 26: Transportation Of Your Product

    E- CLEANING, MAINTENANCE AND TRANSPORTATION OF YOUR PRODUCT Transportation of your product Unplug your product from the grounded outlet. Carry out defrost operation. Carry your product at normal using position. Do not carry horizontally, vertically, tilted or with the door open.

  • Page 27: Troubleshooting

    F- THINGS THAT MUST BE DONE BEFORE CALLING AUTHORIZED SERVICE Troubleshooting The failures and solutions stated in this section can be performed easily by yourselves and always consult to an Authorized Service if these suggestions do NOTE solve your problem. CAUTION! •...
  • Page 28 A1304000028...

This manual is also suitable for:
