Summary of Contents for Createq BRIQX 4K30
- Page 1 USER MANUAL FOR BRIQX 4K30 MEDIAPLAYER V1.3 November 2022...
-
Page 2: Table Of Contents
Audio commands ...................... 8 Output resolution commands.................. 9 CONNECTING THE MEDIAPLAYER ................10 Connectors available on mediaplayer ..............10 TROUBLESHOOTING ....................11 FAQ ........................... 11 How to contact us for technical assistance ............13 THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL... -
Page 3: Introductory
INTRODUCTORY Congratulations with your purchase of the BRIQX 4K30 mediaplayer with overlay support. This compact mediaplayer is designed with special use cases in mind that vary from continues videoloop installations to playback of videos triggered by user interactions like button pushes or other interfaces (motion sensor, tablet interaction etc.) in combination with other BRIQX products by Createq. -
Page 4: Contents
USB-A to USB-C cable 2m (KU.25.0202.01) HDMI cable 3m (KH.25.0020.03) Optical cable 1m (KO.25.0001.01) Optical cable 3m ( KO.25.0003.01) Simple Button/Trigger Experience (ET.80.0010.01) The above items can be ordered separately when placing your BRIQX 4K30 mediaplayer order. THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL... -
Page 5: Setting Up Products For Use With The Demo Set
3. RAW Passthrough – Bitstreams audio over HDMI Firmware Version – Shows the currently installed firmware version Factory Reset – Provides a factory reset of the player, will also wipe all content and resets all setting to default. THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL... -
Page 6: Files
All videos must be placed into the /autoplay folder in the root of the USB pendrive. The attract loop videos must start their filename with Axx__ (that is two underscores) So, the first file is named A01__xxxxxxx.mp4 The second file is named A02__xxxxxxx.mp4 etc. THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL... -
Page 7: Selection Videos
USB pendrive and not only the files that you want to update, but this is also because all the local files on the player will be deleted prior to transferring the new files to the player. THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL... -
Page 8: Commands
Using the V00 command will jump right back to the A01 file and start playing it and the loop. There is a maximum of 99 trigger video files possible, A01 – A99. THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL... -
Page 9: Overlay Commands
AUDIO01 = Normal Audio setting (HDMI + Optical) AUDIO02 = SPDIF Audio setting (Optical Only) AUDIO03 = Bitstream Audio setting (HDMI Only) Please note that Dolby Atmos audio is only supported using the AUDIO03 Bitstream setting on the mediaplayer. THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL... -
Page 10: Output Resolution Commands
RESOLUTION04 = 1920x1080p 50fps RESOLUTION05 = 1920x1080p 60fps RESOLUTION06 = 3840x2160p 24fps RESOLUTION07 = 3840x2160p 25fps RESOLUTION08 = 3840x2160p 30fps RESOLUTION09 = 3840x2160p 50fps RESOLUTION10 = 3840x2160p 60fps RESOLUTION11 = 1280x720p 50fps RESOLUTION12 = 1280x720p 60fps THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL... -
Page 11: Connecting The Mediaplayer
Reset – Boot the player holding the reset button pressed down with a pin for 15 seconds and the player is reset to it’s default state, WARNING!, THIS WILL ALSO WIPE ALL VIDEOS AND OVERLAYS PRESENT ON THE PLAYER THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL... -
Page 12: Troubleshooting
Does the BRIQX 4K30 mediaplayer support HDR or Dolby Vision? No it does not, if these formats are required please contact Createq for other options. Does the mediaplayer support advanced audio formats? Yes the BRIQX 4K30 mediaplayer supports digital audio up to and including Dolby Atmos™... - Page 13 How can I test the players functions? The players are shipped with 3 files already in it’s internal memory, A01, V01 and OVL01, these can be used to test the video and audio output of the player THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL...
-
Page 14: How To Contact Us For Technical Assistance
For technical assistance please contact us at : Createq B.V. Het Witte Hert 14 1601MJ Enkhuizen Netherlands +31(0)228 321155 info@createq.nl *The product images shown are for illustration purposes only and may not be an exact representation of the product. THE SPECIALIST IN TECHNICAL RETAIL SOLUTIONS WWW.CREATEQ.NL...
