Installation manual WinLed Skyline
60
1
3061
1530
750
Mounting clip type 1
For chain assembly.
Art. Number: LL600OH
2
.
Not included
Attach the clips to a chain and then the profile
3
.
1.
1
0
OFF
2.
Lock the profiles by
tightening the two
screws that are
included.
4
.
24-08-2016
750
Not included,
Order separately
Type 1
Linking profiles
SECTION B-B
3136
3061
4668
4592
Connector placing
1530
750
Mount the clips to a ceiling and then the profile
3.
SECTION A-A
Snap the connectors
together.
V2.0
4592
1530
Mounting clip type 2
For surface mounting or
threaded rod.
Art. Number: LL600PB
Type 2
Position the profiles next to
each other. Make sure
they're levelled. Then slide
the profiles on each other.
CLICK
!
Art. Number:
LL600PR3.0M
Art. Number:
LL600PR4.5M
750
